National Instruments NI-9262 C Series Voltage Output Module
The National Instruments NI-9262 (Part Number: 785503-01) is a 6-Channel Voltage Output Module with 1 MS/s/ch simultaneously updating capability. This model comes featured with short-circuit protection, low crosstalk, fast slew rate, overvoltage protection, and a high relative accuracy. For maximum prevention against noise immunity and better safety, the NI 9262 comes with 60 V DC, CAT I channel-to-earth ground isolation barrier. This 16-bit resolution device is offered with 37-Pin DSUB connectivity and can be used with the National Instruments NI-9923 Screw-Terminal Block.
The NI-9262 module has ±10 V output range. This device offers ±10 mA current driver per channel, 1 nF capacitive drive, 0.6 Ω output impedance, 150 µV RMS Noise (at 0.1 Hz to 1 MHz), 5 V/µ slew rate, and 0 V power on state. Each of the two channels provided on this device has its own digital-to-analog converter (DAC) that generates a voltage signal. The AO-to-COM overvoltage protection incorporated in the NI 9262 is set at ± 30 V maximum.
The NI-9262 can operate with a minimum update time as low as 1.5 µs. Users can achieve 1 MS/s FPGA based user controlled I/O sampling rate of 1 MS/s with this module. As verified through a 5 s dielectric withstand test, this model offers 1,000 V RMS, withstand isolation between channel-to-earth ground. With low channel-to-channel crosstalk (10 kHz) of -100 dB, the National Instruments NI-9262 Voltage Output Module offers better accuracy performance. In typical measurement conditions, an adequately calibrated NI-9262 can operate with a 0.06% gain error and 0.01% offset error.
| Model | NI-9262 |
|---|---|
| Manufacturer | National Instruments |
| Part Number | 785503-01 |
| Type | C Series Voltage Output Module |
| Analog Output Channels | 6 |
| Maximum Update Rate | 1 MS/s per channel |
| Analog Output Resolution | 16 bits |
| Front Connector | D-Sub |
| Calibration Interval | 2 years |
| NI-9262 Manual | User Manual and Maintenance Manual Available for Download |
| Price | Contact a sales representative for a quote. |
Associated part numbers for NI-9262:
National Instruments NI-9262 Frequently Asked Questions
Question: Are any accessories required for the NI 9262?
Answer: The NI 9923 Front-mount Terminal Block for 37-pin D-Sub Modules is required for the NI 9262.
Question: Does the NI-9262 have channel-to-channel isolation?
Answer: No, the NI-9262 does not have channel-to-channel isolation.
Question: Which types of analog output connections does the NI 9262 have?
Answer: The NI 9262 has analog output signal connections (AO), common reference connections (COM), and no connections (NC).
Question: Can the NI-9262 be used on the CompactRIO platform in scan mode?
Answer: No, the NI-9262 can only be used on the CompactRIO platform in FPGA mode.
