cDAQ-9138

4.9/5 | 14 ratings

Modular Systems > National Instruments > CompactDAQ

Part Number cDAQ-9138
Manufacturer/Brand National Instruments
Description: cDAQ-9138, 8-Slot, CompactDAQ Controller
In Stock | Ships in 5-10 Days
(expedited shipping options available)
Fast Quote
Quoted Price
Same Day Calibration Available
2-3 Year Warranty Included
Free Ground Shipping
  Get Pricing

Need an Official Quote?



Or speak to a sales representative for pricing & lead time:


National Instruments cDAQ-9138 CompactDAQ Controller

Featured with a Dual-Core 1.06 GHz Intel Celeron U3405 processer, the National Instruments cDAQ-9138 (Part Number: 782323-01 and 782324-01) is an 8-Slot Controller. This model controls the data transfer, timing, and synchronization between an integrated computer and C Series I/O modules. For embedded monitoring and data controlling, the NI cDAQ-9138 comes equipped with 32 GB nonvolatile storage. With this microprocessor based controller, the user will be able to choose between running LabVIEW Real-Time software and Windows Embedded Standard.

The National Instruments cDAQ-9138 offers a broad range of expansion and standard connectivity slots, including: RS-485/422 serial, USB, RS232 serial, Ethernet, and MXI-Express. For a custom digital I/O, analog I/O, and CAN (controller area network), logging and measurement system, the user can combine their cDAQ-9138 with as many as eight C Series I/O modules.

Through its analog input, the cDAQ 9138 can acquire samples at 12.5 ns timing resolution and 50 ppm timing accuracy. This CompactDAQ Controller comes with 4 integrated counters/timers that support pulse, period, pulse width, semi-period, edge counting, and two-edge separation counter measurements.

The MXI-Express Port provided in this Controller offers communications at a rate of 2.5 Gbit/s and supports up to 7 m maximum cabling distance. For USB based communications, four USB 2.0, Hi-Speed ports can also be utilized. The NI cDAQ-9138 can be operated over a voltage input range of 9 V to 30 V. This Controller consumes 75 watts of power maximum while operating in standard configuration and operating conditions. This model weighs around 2.8 kg.

ModelcDAQ-9138
ManufacturerNational Instruments
Part Numbers782323-01 and 782324-01
TypeCompactDAQ Controller
Slots8
CPUIntel Celeron U3405
CPU Frequency1.06 GHz
Dimensions15.80 in. × 3.47 in. × 4.78 in.
Weight6.16 lb.
WarrantyOne Year Warranty
cDAQ-9138 ManualUser Manual and Maintenance Manual Available for Download
PriceContact a sales representative for a quote.

National Instruments cDAQ-9138 Frequently Asked Questions



Question: What is the difference between the two part numbers for the cDAQ 9138?



Answer: The cDAQ 9138 has two part numbers, each with a different operating system. Part number 782323-01 is for Windows OS and part number 782324-01 is for Real-Time OS.



Question: Is hyper-threading supported on the cDAQ 9138?



Answer: No, hyper-threading is not supported on the cDAQ 9138.



Question: How many USB ports does the NI cDAQ-9138 have?



Answer: The NI cDAQ-9138 has four USB ports.



Question: What is the accuracy of the internal real-time clock on the cDAQ-9138?



Answer: The internal real-time clock on the cDAQ-9138 has an accuracy of 140 ppm, maximum.

  cDAQ-9138 PDF Manuals

Driver Downloads for cDAQ-9138






OS Compatibility:
Win XP 32-bit, Win 7 32-bit, Win 10 32-bit

 Download Version


Why Buy From Apex Waves:

Apex Waves Youtube Video


Delivery:
UPS, FedEX and DHL – Free FedEx Ground on all orders
Overnight, Next Day Air or Expedited shipping options available
International delivery available
Same day shipping for in-stock on location
Warranty: All of our products are covered by our Apex Waves Warranty.
3 Year Warranty - New Surplus Parts
2 Year Warranty - Refurbished Parts
Returns: No hassle return policy.
Dedicated customer service team.
Payment:
Quick Quotes: Receive Price & Availability Today!
Calibration: Ask About Our Tiered Calibration Levels
Option & Modules: Confirm Your Requirements or Versions
Repair: Cost & Lead Time Available Upon Request for Service
Repair Evaluation: $150
Share this page:
Associated Part Numbers:
Common Typos: CVAQ-9138, CDQQ-9138, CDAQ-9Q38, CDAQ-91W8, CDAQ-913I

cDAQ-9138


cDAQ-9138

cDAQ-9138, 8-Slot, CompactDAQ Controller

In Stock | Ships in 5-10 Days
(expedited shipping options available)
Same Day Calibration Available
2-3 Year Warranty Included
Free Ground Shipping
  Get Pricing

Call now for best pricing
1-800-915-6216

National Instruments cDAQ-9138 CompactDAQ Controller

Featured with a Dual-Core 1.06 GHz Intel Celeron U3405 processer, the National Instruments cDAQ-9138 (Part Number: 782323-01 and 782324-01) is an 8-Slot Controller. This model controls the data transfer, timing, and synchronization between an integrated computer and C Series I/O modules. For embedded monitoring and data controlling, the NI cDAQ-9138 comes equipped with 32 GB nonvolatile storage. With this microprocessor based controller, the user will be able to choose between running LabVIEW Real-Time software and Windows Embedded Standard.

The National Instruments cDAQ-9138 offers a broad range of expansion and standard connectivity slots, including: RS-485/422 serial, USB, RS232 serial, Ethernet, and MXI-Express. For a custom digital I/O, analog I/O, and CAN (controller area network), logging and measurement system, the user can combine their cDAQ-9138 with as many as eight C Series I/O modules.

Through its analog input, the cDAQ 9138 can acquire samples at 12.5 ns timing resolution and 50 ppm timing accuracy. This CompactDAQ Controller comes with 4 integrated counters/timers that support pulse, period, pulse width, semi-period, edge counting, and two-edge separation counter measurements.

The MXI-Express Port provided in this Controller offers communications at a rate of 2.5 Gbit/s and supports up to 7 m maximum cabling distance. For USB based communications, four USB 2.0, Hi-Speed ports can also be utilized. The NI cDAQ-9138 can be operated over a voltage input range of 9 V to 30 V. This Controller consumes 75 watts of power maximum while operating in standard configuration and operating conditions. This model weighs around 2.8 kg.

ModelcDAQ-9138
ManufacturerNational Instruments
Part Numbers782323-01 and 782324-01
TypeCompactDAQ Controller
Slots8
CPUIntel Celeron U3405
CPU Frequency1.06 GHz
Dimensions15.80 in. × 3.47 in. × 4.78 in.
Weight6.16 lb.
WarrantyOne Year Warranty
cDAQ-9138 ManualUser Manual and Maintenance Manual Available for Download
PriceContact a sales representative for a quote.

National Instruments cDAQ-9138 Frequently Asked Questions



Question: What is the difference between the two part numbers for the cDAQ 9138?



Answer: The cDAQ 9138 has two part numbers, each with a different operating system. Part number 782323-01 is for Windows OS and part number 782324-01 is for Real-Time OS.



Question: Is hyper-threading supported on the cDAQ 9138?



Answer: No, hyper-threading is not supported on the cDAQ 9138.



Question: How many USB ports does the NI cDAQ-9138 have?



Answer: The NI cDAQ-9138 has four USB ports.



Question: What is the accuracy of the internal real-time clock on the cDAQ-9138?



Answer: The internal real-time clock on the cDAQ-9138 has an accuracy of 140 ppm, maximum.

cDAQ-9138 PDF Manuals & Diagrams

  cDAQ-9138 PDF Manuals

NI CDAQ 9138 9139 LETTER OF VOLATILITY.PDF

NI CDAQ 9138 9139 USER MANUAL.PDF

NI CDAQ 9138 9139 FOR LABVIEW REAL TIME QUICK START.PDF

NI CDAQ 9138 9139 FOR WINDOWS QUICK START.PDF

NI CDAQ 9138 SAFETY ENVIRONMENTAL AND REGULATORY INFORMATION.PDF

NI CDAQ 9138 SPECIFICATIONS.PDF

CDAQ CHASSIS AND CONTROLLERS CALIBRATION PROCEDURE.PDF
