National Instruments cRIO-9033 CompactRIO Controller

The cRIO-9033 is an embedded CompactRIO Controller by National Instruments. The part number of the cRIO-9033 is 783452-01. This model is designed for monitoring applications where advanced user control is required. The cRIO-9033 can run the Linux RT operating system. Thus, it is compatible with Linux family applications and products. This model also features a user interface capability. This feature allows the user to add HMI and greatly simplifies the development of applications. The cRIO 9033 can be interfaced with a host network or computer. The startup options are configurable. The USB device port or Ethernet port is used for this purpose.

The NI cRIO-9033 CompactRIO Controller has a dual-core processor with a clock frequency of 1.33 GHz. The NI cRIO 9033 has two Ethernet ports. These ports support 10, 100, and 1000 Mbps communication speeds. This model also has two ports for serial communication. These ports are an RS-232 port and an RS-485/422 port. The baud rate of these ports is 115.2 kbps. The cRIO-9033 also features one USB device and two USB host ports. Each port can transfer data at a maximum rate of 480 Mbps. The mini display port can support a maximum resolution of 2560 x 1600 at 60 Hz.

The cRIO-9033 CompactRIO Controller is suitable for a variety of applications. This high-performance waveform acquisition device can process signaling and is ideal for control applications where high-speed is required. The cRIO-9033 can perform unique timing and triggering tasks. The Controller is also used for communication and synchronization over Ethernet networks and can be used to design complex monitoring and control systems.
