cRIO-9104

Modular Systems > National Instruments > CompactRIO Controllers

Part Number cRIO-9104
Manufacturer/Brand National Instruments
Description cRIO-9104 8-Slot, FPGA, Legacy CompactRIO Chassis
In Stock - Ships Today
In Stock | Ships 3-5 Days

Speak to a sales representative for pricing & lead time:


National Instruments cRIO-9104 CompactRIO Chassis

With the cRIO9104 (Part Numbers: 779054-02 and 779054-01), each CompactRIO I/O module contains worked in signal molding and screw terminal, BNC, or D-Sub connectors. By coordinating the connector intersection enclose to the modules, the CompactRIO framework fundamentally lessens the space necessities and cost of field wiring. An assortment of I/O composes are accessible including ±80 mV thermocouple inputs, ±10 V synchronous inspecting simple sources of input/outputs, and 24 V modern computerized I/O with up to 1 A of current. Utilizing the LabVIEW FPGA Module and reconfigurable equipment innovation, the user can make ultra-high execution control and procurement frameworks with CompactRIO. The FPGA hardware is a parallel preparing reconfigurable processing motor that executes the LabVIEW application in silicon hardware on a chip. The LabVIEW FPGA Module highlights fifth-arrange FIR channels, 1D look-into tables, straight insertion, zero intersection identification, and direct advanced union of sine waves.

Utilizing the implanted RIO FPGA equipment, the user can execute multi-loop simple PID control frameworks at circle rates surpassing 100 kS/s. Computerized control frameworks can be actualized at circle rates up to 1 MS/s. Different rungs of Boolean logic can be assessed utilizing single-cycle while circles at 40 MHz (25 ns). Despite the parallel idea of the RIO center, including extra calculations does not really decrease the speed of the FPGA application. CompactRIO offers 4 and 8-opening chassis with choices for FPGA chips with either 1 million or 3 million entryways.

This model offers small, tough, modern control and procurement framework and a powered by reconfigurable I/O (RIO) FPGA innovation for high execution and customization.

ModelcRIO-9104
ManufacturerNational Instruments
Part Numbers779054-01, 779054-02
TypeCompactRIO Chassis
Slots8
FPGA3 M Gate
Logic Slices5,120
Embedded RAM81,920 bytes
Weight28 oz.
WarrantyOne Year Warranty
cRIO-9104 ManualUser Manual and Maintenance Manual Available for Download
PriceContact a sales representative for a quote.

National Instruments cRIO-9104 Frequently Asked Questions



Question: What should I do when my cRIO-9104 gets a flashing status light error?



Answer: If you get a flashing status light error with the cRIO-9104, restart it in either No App or Safe Mode.



Question: If I want to put the NI cRIO-9104 in a tight enclosed area, what do I need to know about overheating?



Answer: You can calculate the heat dissipation from the maximum power consumption from the NI cRIO-9104 chassis, the average consumption of the chassis and modules, and lastly by empirically testing the power consumption of the CompactRIO Chassis and modules. Each one has a descending safety factor.



Question: Can you design your own custom control with the cRIO 9104?



Answer: The cRIO 9104 allows you to design your own custom control or acquisition circuitry in silicon with 25 ns timing/triggering resolution.
