Part Number 778629-01
Manufacturer/Brand National Instruments
Description: 778629-01, 8 Digital I/O Lines, Two 24 Bit Counters, 16 Analog Input, PCI-6013 Multifunction DAQ
Request for Availablility
Fast Quote
Quoted Price
Same Day Calibration Available
2-3 Year Warranty Included
Free Ground Shipping
  Get Pricing

Need an Official Quote?



Or speak to a sales representative for additional information:


National Instruments 778629-01 Multifunction DAQ

The multifunction data acquisition (DAQ) device, part number 778629-01 by National Instruments, is intended for a wide range of applications in industrial automation, laboratory automation, research, design verification/test, and production test. It is an identifying part number for the PCI-6013 model. Because it incorporates counters, digital I/O, analog input, and digital triggering into one unit, it is adaptable and appropriate for a range of OEM products as well as straightforward applications.

There are two selectable input modes available for this DAQ device: differential (DIFF) and nonreferenced single-ended (NRSE). In order to provide flexible configuration based on application needs, NRSE mode allows up to 16 channels, whereas DIFF mode supports up to eight channels.

To maximize the resolution of the analog-to-digital converter (ADC), each channel can be independently programmed with gains of 0.5, 1.0, 10, or 100 thanks to the device's bipolar input range, which adapts to the specified gain.

The 778629-01 has eight lines of digital I/O (DIO<0..7>), which can be software-configured for input or output, in addition to analog input. The general-purpose capability of these digital I/O lines increases the device's adaptability to a range of automation and control applications.

In addition, the device has two 24-bit counters and digital triggering capabilities, which allow for accurate timing management and synchronization in applications such sampling rates that change smoothly and pulse generation and equivalent time sampling.

The 778629-01's inbuilt DAQ-STC (data acquisition system timing controller) chip makes it easier to perform time-related tasks like counter/timer, AO, and AI. It consists of three timing groups, each with a maximum timing resolution of 50 ns and control over distinct functions.

Moreover, the I/O connection of the device has Programmable Function Input (PFI) pins, which allow for flexible interaction with external electronics. These connections improve the device's integration possibilities in intricate automation systems by enabling it to control and be controlled by other devices and circuits.

Part Number778629-01
Model NamePCI-6013
Part TypeMultifunction I/O Device
Analog Input Channels16
Analog Input Resolution24-bit
Digital I/O Lines8
Counter/Timers2 (24-bit)
Maximum Timing Resolution50 ns
Input ModesNRSE or Differential
Input Gain Options0.5, 1.0, 10, 100
