National Instruments PCI-6515 Digital I/O Device

The PCI-6515 (Part Number: 778835-01) is a 32 Digital Input Channel, 32 Digital Output Channel Digital I/O Device by National Instruments. This low-cost, industrial Digital I/O Device has advanced features for industrial control, manufacturing test, and data acquisition applications. When powering up, the output drives on this device are incapacitated. All output lines are client configurable for an on or off state. Client configurable catalyst states are helpful for guaranteeing that the NI PCI 6515 powers up in a known state. To utilize MAX (prescribed) to program the catalyst states, select the gadget and tap the Properties button. The user can refer to the product documentation for data about how to program the catalyst states utilizing NI-DAQ with LabVIEW or other National Instruments application improvement situations. The user can program the NI PCI-6515 device to send an interrupt when a change happens on any information line. The DIO device can screen changes on chosen input lines or on all information lines. This device can screen for rising edges (0 to 1), falling edges (1 to 0), or both. When an information change happens, the DIO Device creates an interrupt and the NI-DAQ driver advises the product.

The DIO Device sends a change discovery when any of the progressions happen, yet it does not report which line changed or if the line was rising or falling. After a change, the user can read the info lines to decide the present line states. The greatest rate of progress location is dictated by the product reaction time, which differs from framework to framework. An overflow bit shows that an extra rising or falling edge has been distinguished before the product could process the past change.

ModelPCI-6515
ManufacturerNational Instruments
Part Number778835-01
TypeDigital I/O Device
Digital Input Channels32
Digital Output Channels32
Voltage Range-30 V to 30 V
Dimensions6.3 in. × 3.9 in.
Weight6.1 oz.
WarrantyOne Year Warranty
PCI-6515 ManualUser Manual and Maintenance Manual Available for Download
PriceContact a sales representative for a quote.

National Instruments PCI-6515 Frequently Asked Questions



Question: What is the single-ended digital I/O channel current drive for the PCI-6515?



Answer: The single-ended digital I/O channel current drive for the PCI-6515 is 125 mA.



Question: Which accessories are required for the NI PCI-6515?



Answer: The SCB-100A Noise Rejecting, Shielded I/O Connector Block and SH100-100-Flex Cable Assembly are required accessories for the NI PCI-6515.



Question: What type of isolation does the PCI 6515 have?



Answer: The PCI 6515 has bank isolation.



Question: Which type of I/O connector is on the NI PCI 6515?



Answer: The NI PCI 6515 has a 100-pin keyed female SCSI I/O connector.


PCI-6515 Technical Specifications:

Manufacturer:National Instruments
Model:PCI-6515
Part Number:778835-01
Type:Digital I/O Device
Repair Evaluation:$150
