National Instruments PCI-6534 Digital I/O Device

The PCI-6534 (Part number: 778287-01) is synchronized with different kinds of estimations, including high-speed simple input, digitizers, sources, simple output, counter/clocks, image obtaining, movement control, and CAN interfaces. By individually using CPULL and DPULL, information lines and the power-on state for the control can be autonomously selected. With the NI PCI-6534 device, the user can create event driven application programs by programming them to produce a memo when conditions they need are met. These memos can be produced when a predetermined quantity of bytes have been exchanged, when a predefined input design is coordinated, or when an estimation task finishes.

The PCI-6534 National Instruments Device can be used for a function created by NI called MITE PCI interface. The MITE gives bus-master tasks, PCI burst exchanges, and elite DMA controllers for quick, nonstop, dissipate assemble DMA.

The nonstop sample I/O benchmark arranges the NI PCI-6534 gadget for persistently refreshed twofold supported exchange at a chosen exchange rate. If the chosen exchange rate is too high, a normal mistake will happen. The rate of exchange automatically abatements and the exchange begins once more. Once 100 MB are exchanged without blunder, the benchmark stops. For NI PCI 6534 gadgets, the exchange rate is restricted by the PC equipment and framework, not the advanced I/O gadget

This model comes with Single-Shot Pattern I/O, which is the benchmark for single shot example I/O. This feature enables the device to exchange a limited measure of information a given number of times.

ModelPCI-6534
ManufacturerNational Instruments
Part Number778287-01
TypeDigital I/O Device
Digital Inputs/Outputs32 (5 V TTL/CMOS Compatibility)
Maximum Rate5 MHz (pattern I/O), 19.9 MHz (handshaking)
Memory64 MB, two 32 MB modules
I/O Connector68-pin male SCSI-II type
Power Requirements+5 V -- 2.0 A
Dimensions6.9 by 4.2 in.
Software DriverNI-DAQ
WarrantyOne Year Warranty
PCI-6534 ManualUser Manual and Maintenance Manual Available for Download
PriceContact a sales representative for a quote.
