National Instruments PXIe-6537 PXI Digital I/O Module

The 32 Channel, 50 MHz, 200 MB/s, National Instruments PXIe-6537 (Part Number: 779989-01) Digital I/O Module, executes the diverse simple info ground-reference settings by directing distinctive signals to the NI-PGIA. The NI-PGIA is a differential enhancer. That is, the NI-PGIA enhances (or constricts), the distinction in voltage between its two data sources. The NI-PGIA drives the ADC with this opened voltage. In the single-ended modes, there are more electrostatic and attractive noise couples in the signal associations than in DIFF setups. The coupling is the consequence of contrasts in the signal path. Attractive coupling is relative to the area between the two signal conductors. Electrical coupling is an element of how much the electric field contrasts between the two transmitters. With this kind of association, the NI-PGIA rejects both the regular mode noise in the signal and the ground potential contrast between the signal source and the gadget ground.

It is vital to interface the negative lead of a drifting signal source to AI GND (specifically through a resistor). Generally, the source may float out of the legitimate information scope of the NI-PGIA and the DAQ gadget returns wrong information. Pre-triggered information acquisition enables the user to see information that is gained before the trigger of interest, notwithstanding information obtained after the trigger. AI Start Trigger (ai/StartTrigger) can be either a hardware or software signal. If an AI Start Trigger is set up to be programming a begin trigger, an output press shows up on the ai/StartTrigger line when the acquisition starts.

ModelPXIe-6537
Part Number779989-01
ManufacturerNational Instruments
TypePXI Digital I/O Module
Bidirectional Digital Channels32
Digital Input Voltage Range-1 V to 6 V
Output Voltage Range0 V to 5 V
Dimensions8.42 x 0.79 x 5.14 in.
Weight5.1 oz.
WarrantyOne Year Warranty
PXIe-6537 ManualUser Manual and Maintenance Manual Available for Download
PriceContact a sales representative for a quote.

National Instruments PXIe-6537 Frequently Asked Questions



Question: What is the maximum clock rate for the PXIe-6537?



Answer: The PXIe-6537 has a maximum clock rate of 50 MHz.



Question: Which driver software should be used with the NI PXIe-6537?



Answer: The driver software meant for use with the NI PXIe-6537 is NI-DAQmx version 8.5 or later.



Question: What cable length is optimal for the PXIe 6537?



Answer: The PXIe 6537 should be used with a 1 m cable. A longer cable may not achieve the specifications listed in the datasheet/manual.



Question: What is the total power for the NI PXIe-6537?



Answer: The total power for the NI PXIe-6537 is 6.1 W.

PXIe-6537 Technical Specifications:


Manufacturer:National Instruments
Model:PXIe-6537 (779989-01)
Type:PXI Digital I/O Module
Repair Evaluation:$150
