National Instruments AT-MIO-16E-1 Multifunction I/O Device
The AT-MIO-16E-1 (Part Number: 777142-01) is a Multifunction I/O Device developed by National Instruments. The AT-MIO-16E-1 belongs to the AT-MIO/AI E Series of data acquisition (DAQ) devices. These devices utilize E Series technology to render high performance and DAQ capabilities. The NI AT-MIO-16E-1 can be utilized with multiple types of application software like LabView, Measurement Studio, and VI Logger. The NI-DAQ driver software is used to configure the AT-MIO-16E-1. This Multifunction I/O Device can only be operated on Windows 2000/NT/Me/9x operating systems.
The NI AT-MIO-16E-1 is the first device with unique features when compared to other DAQ devices. The AT-MIO-16E-1 is developed as a switchless and jumper-less DAQ device. The AT-MIO-16E-1 can be calibrated for three different kinds of input configuration: differential (DIFF) terminal configuration, RSE terminal configuration, and non-referenced single-ended (NRSE) terminal configuration. This Multifunction I/O Device uses the DAQ-STC time controller to meet requirements for time-related functions.
The AT-MIO-16E-1 device is configured with 16 analog input channels with an input voltage range from ±10 to ±0.05 V, 2 analog output channels with ±10 V output voltage, and 8 digital TTL/CMOS input/output lines. This Multifunction I/O Device comes with an input/output impedance of 10k Ω/ 0.1Ω. The NI AT-MIO-16E-1 comes with DC input/output coupling. The AT-MIO-16E-1 additionally has two 24-bit, 20 MHz timers to count up/down variations. This device is designed with a 68-pin male 0.050 D type connector. The NI AT-MIO-16E-1 Multifunction I/O Device delivers a high sampling rate of 1.25 MS/s.
| Model | AT-MIO-16E-1 |
|---|---|
| Manufacturer | National Instruments |
| Part Number | 777142-01 |
| Series | AT-MIO/AI E Series |
| Type | Multifunction I/O Device |
| Analog Input Channels | 16 SE/8 DI |
| Analog Output Channels | 2 |
| Resolution | 12 bits |
| Maximum Sampling Rate | 1.25 MS/s |
| Bus Interface Type | Slave |
| Dimensions | 13.3 by 3.9 in. |
| Warranty | 2-3 Year Warranty |
| AT-MIO-16E-1 Manual | User Manual and Maintenance Manual Available for Download |
| Price | Contact a sales representative for a quote. |
Associated part numbers for the AT-MIO-16E-1:
18301.8, 183018-01, 183018B-01, 183018C-01, 183018D-01, 183018F-01, 777142-00, 777142-01, 777142-03
National Instruments AT-MIO-16E-1 Frequently Asked Questions
Question: What is the FIFO buffer size of the AT-MIO-16E-1?
Answer: The FIFO buffer size of the AT-MIO-16E-1 is 8,192 samples.
Question: Which cables can be used with the NI AT-MIO-16E-1?
Answer: The NI AT-MIO-16E-1 has 68 pins that can be connected to 68-pin accessories with the use of the R6868 ribbon cable or the SH6868 shielded cable. In addition, the SH6850 shielded cable or R6850 ribbon cable can be used to connect the NI AT-MIO-16E-1 to 50-pin signal conditioning modules and accessories.
Question: Does the AT-MIO-16E-1 support analog triggering?
Answer: Yes, the AT-MIO-16E-1 supports analog triggering on the PFI0/TRIG1 pin.
