National Instruments AT-MIO-16XE-10 Multifunction DAQ
The NI AT-MIO-16XE-10, (Part Number: 777181-01), utilizes E Series innovation to convey elite, solid information procurement capacities to meet an extensive variety of prerequisites. The device has 16-bit resolution with 16 analog input channels. Contingent upon the type of hard drive, this board can stream information to plate at rates up to 100 kS/s maximum. The NI AT-MIO-16XE-10 device is compatible with the business standard Plug and Play ISA detail. This model includes a Plug and Play framework that parleys and allots assets through programming, liberating he user from physically configuring switches and jumper’s settings. These assets incorporate DMA channels, board base I/O address, and the capacity to interfere with channels. The user can utilize a NI AT-MIO-16XE-10 device in a non-Plug and Play framework as a switchless DAQ board. The NI AT-MIO-16XE-10 can accomplish high exchange rates by utilizing around three 16-bit DMA channels. The user can utilize these DMA channels for information exchanges with the simple info, simple yield, and universally useful counter segments of the board.
This Multifunction DAQ can be used with two types of accessories: the SH68-68-EP (Part Number: 184749-01) Noise Rejecting, Shielded Cable which is 1 m in length and the SCC-68 (Part Number: 779475-01) I/O Connector with 4 SCC Module Slots.
The NI AT-MIO-16XE-10 Multifunction DAQ can build transport proficiency by utilizing an interfere with channel. The user can utilize an interfere with channel for occasion warning without the utilization of surveying methods. The simple info segment of every NI AT-MIO-16XE-10 is programming configurable. The user can choose distinctive simple information setups through application programming intended to control the National Instruments AT-MIO-16XE-10 DAQ.
| Model | AT-MIO-16XE-10 |
|---|---|
| Manufacturer | National Instruments |
| Part Number | 777181-01 |
| Type | Multifunction DAQ |
| Analog Input Channels | 16 |
| Analog Output Channels | 16 |
| Digital I/O Lines | 8 |
| Maximum Sample Rate | 100 kS/s |
| Dimensions | 13.3 by 3.9 in. |
| AT-MIO-16XE-10 Manual | User Manual and Maintenance Manual Available for Download |
| Price | Contact a sales representative for a quote. |
Associated part numbers for AT-MIO-16XE-10:
National Instruments AT-MIO-16XE-10 Frequently Asked Questions
Question: Can I disable dither on the AT-MIO-16XE-10?
Answer: No, the user cannot disable dither on the AT-MIO-16XE-10 since the resolution of the ADC is so fine that the ADC and the PGIA innately generate nearly 0.5 LSB of noise.
Question: What is the output voltage range of the NI AT-MIO-16XE-10?
Answer: The output voltage range of the NI AT-MIO-16XE-10 is software selectable from unipolar ((0 to 10 V) and bipolar (+10 V).
Question: What type of ADC does the AT-MIO-16XE-10 have?
Answer: The AT-MIO-16XE-10 has a successive approximation ADC.
Question: Does the NI AT-MIO-16XE-10 have overvoltage protection?
Answer: Yes, the NI AT-MIO-16XE-10 has ±25 V overvoltage protection while on and ±15 V while turned off.
AT-MIO-16XE-10 PDF Manuals
ARCHIVED--AT-E-SERIES-USER-MANUAL.PDF
ARCHIVED--AT-MIO-E-SERIES-REGISTER-LEVEL-PROGRAMMER-MANUAL.PDF
ARCHIVED--E-SERIES-CALIBRATION-PROCEDURE--FOR-TRADITIONAL-NI-DAQ-5BLEGACY5D-.PDF
ARCHIVED--LABVIEW-DATA-ACQUISITION-BASICS-MANUAL.PDF
ARCHIVED--LABVIEW-FUNCTION-AND-VI-REFERENCE-MANUAL.PDF
ARCHIVED--MEASURE-DATA-ACQUISITION-USER-MANUAL.PDF
ARCHIVED--NI-DAQ-USER-MANUAL-FOR-PC-COMPATIBLES.PDF
ARCHIVED--NOTE-TO-USERS--WARNING--MAXIMUM-SIGNAL-RATINGS-FOR-MIO-AI-E-SERIES-BOARDS.PDF
ARCHIVED--RELEASE-NOTES--USING-YOUR-NI-DAQ-SOFTWARE-WITH-YOUR-VXI-DAQ-MODULE.PDF
ARCHIVED--TRADITIONAL-NI-DAQ-USER-MANUAL.PDF
DAQ-GETTING-STARTED-GUIDE-FOR-PCI-PCI-EXPRESS.PDF
DAQ-GETTING-STARTED-READ-ME-FIRST--NI-DAQMX-AND-DAQ-DEVICE-INSTALLATION-GUIDE.PDF
