FP-DO-410
Modular Systems > National Instruments > FieldPoint
| Description: | FP-DO-410, 8 Output Channels, Digital Output Module |
Need an Official Quote?
Or speak to a sales representative for additional information:
Phone:1-800-915-6216
Email:sales@apexwaves.com
National Instruments FP-DO-410 Digital Output Module
The FP-DO-410 (Part Number: 777518-410) is a Digital Output Module by National Instruments with eight digital output channels, sourcing outputs, and 5 to 30 VDC voltage range. The output channels on the NI FP-DO-410 can take any incentive between a characterized least and a maximum esteem characterized. The base esteem (minScale) and greatest esteem (maxScale) are characterized by the range setting. The user should consider the channel extend alteration while relating the information esteems in the application and information esteems used in FieldPoint directions ([data]). The information esteems used in the application are otherwise called the building unit esteems (EUVs). Contingent upon how the user sees a discrete channel, they will allude to the declared state as ON, TRUE, HIGH, HI, and to the comparing invalidated state as OFF, FALSE, LOW, LO. Since the range setting for FieldPoint discrete channels is Boolean, the relationship between range setting and information esteem is inconsequential.
To share information, FieldPoint frameworks additionally come arranged with an inherent FTP server, so the user can share put away information and refresh control code and records HTML from remote areas. With the remote boards, the user can utilize a web search tool to associate with the UI of the front board of the LabVIEW application. A few web seek customers can see the front board of LabVIEW and a Web program once the user can perceive how to control the application. Past the average information logger, which basically stores information on an on-load up circle, with LabVIEW Real-Time, the user can make a shrewd information lumberjack inserted in the FP-DO-410.
| Model | FP-DO-410 |
|---|---|
| Manufacturer | National Instruments |
| Part Number | 777518-410 |
| Type | Digital Output Module |
| Digital Output Channels | 8 |
| Output Type | Sourcing |
| Voltage Range | 5–30 VDC |
| Power from Network Module | 450 mW; 620 mW if some or all channels are in short-circuit condition |
| Weight | 4.9 oz. |
| Warranty | 2-3 Year Warranty |
| FP-DO-410 Manual | User Manual and Maintenance Manual Available for Download |
| Price | Contact a sales representative for a quote. |
Associated part numbers for the FP-DO-410:
185849B-01, 777518-410
National Instruments FP-DO-410 Frequently Asked Questions
Question: Are there any stipulations for the output current value for the FP-DO-410?
Answer: If the user is operating the FP-DO-410 in the temperature range between 55 to 70 °C, then the output current should not be higher than 0.5 A on any of the channels.
Question: What is the role of the flyback diodes on the NI FP-DO-410?
Answer: On the NI FP-DO-410, the flyback diodes thwart extremely high voltage from harming the Digital Output Module.
Question: How do I know when a channel has short-circuited on the FP-DO-410 module?
Answer: When a channel on the FP-DO-410 module has short-circuited, the red short-circuit LED for that specific channel lights up. Then, the Digital Output Module will show an error status message to the network module.
Question: What is the output current rating for the NI FP-DO-410?
Answer: The output current rating for the NI FP-DO-410 is 1 A.
FP-DO-410 PDF Manuals
ARCHIVED FP 3000 NETWORK MODULE USER MANUAL.PDF
ARCHIVED FP-DO-410 AND CFP-DO-410 OPERATING INSTRUCTIONS.PDF
ARCHIVED LOOKOUT OBJECT REFERENCE MANUAL.PDF
