National Instruments NI-5782 Transceiver Adapter Module for FlexRIO

The National Instruments NI-5782 is a Transceiver Adapter Module designed for FlexRIO based systems. This 330 MHz bandwidth module is well-suited for applications that require the generation and acquisition of baseband signals, along with real-time, in-line processing. To perform measurement and generate response signals, users can analyze fetched signals in a suitable PXI FPGA module for FlexRIO.

The NI-5782 covers a broad application area that includes: bit error rate testing, radio frequency identification, near-field communication testing, RF modulation, RF demodulation, signal intelligence, software-defined radio testing, and real-time spectrum analysis. The National Instruments NI-5782 is available in two versions: AC-coupled (Part Number: 782705-01) and DC-coupled (Part Number: 782705-02). This module is an immediate-frequency transceiver, which features 2 analog input (AI) channels and 2 analog output channels. The NI-5782 offers up to 250 MS/s on the input channels and up to 500 MS/s can be achieved on the two analog output channels.

This device has all the I/O connectors available on the front panel. The NI-5782 Transceiver Adapter Module has 1 AUX I/O connector, 1 CLK IN connector, 1 TRIG connector, 2 analog input connectors (for Channel-0 and Channel-1), and 2 analog output connectors (for Channel 0 and Channel 1). With the AUX I/O as the only exception, all the NI 5782 Front Panel Connectors operate at 50 Ω input impedance. This device also features CLIP capability that brings additional control and integration features. For various clocking functions, the NI 5782 has a VCO that operates as a free-running clock.

ModelNI-5782
ManufacturerNational Instruments
Part Numbers782705-01, 782705-02
TypeTransceiver Adapter Module for FlexRIO
Analog Input Channels2
Analog Output Channels2
Analog Input Sampling Rate250 MS/s
Dimensions4.5 x 4.0 x 0.8 in.
Weight11.2 oz.
WarrantyOne Year Warranty
NI-5782 ManualUser Manual and Maintenance Manual Available for Download
PriceContact a sales representative for a quote.

National Instruments NI-5782 Frequently Asked Questions



Question: What are the differences between the two part numbers for the NI-5782?



Answer: The NI-5782 has two part numbers with the same specifications, but part number 782705-01 is AC-coupled and part number 782705-02 is DC-coupled.



Question: What do the clocks on the NI-5782 control on the module?



Answer: The clocks on the NI-5782 control the sample rate and various other timing functions.



Question: What is the input impedance of the analog input channels on the NI 5782?



Answer: The analog input channels on the NI 5782 have 50 Ω input impedance for each connector.



Question: What type of oscillator does the internal sample clock have on the NI 5782?



Answer: On the NI 5782, the oscillator for the internal sample clock is a fixed frequency synthesizer.
