Part Number NI-6585B
Manufacturer/Brand National Instruments
Description: NI-6585B, 32 LVDS-Channel, Digital I/O Adapter Module for FlexRIO
Lowest Price Guarantee
Fast Quote
Quoted Price
2-3 Year Warranty Included
Free Ground Shipping
  Get Pricing
2 year warrantyRefurbished
*What is Refurbished?
Quoted Price
Fully tested
2yr warranty
  Get Pricing

Need an Official Quote?


*Most customers receive their price in about 15 minutes.

Or speak to a sales representative for pricing & lead time:


National Instruments NI-6585B Digital I/O Adapter Module for FlexRIO

The National Instruments NI-6585B (Part number: 784060-01) comes with a LabVIEW FPGA module, which stretches out graphical programming to FPGA equipment and gives a single environment for algorithm calculation, simulation, debugging, and assemblage of FPGA plans. Conventional techniques for programming FPGAs require more knowledge of hardware plans and long stretches of experience working with low-level equipment portrayal languages. Regardless of whether users have experience or have never modified a FPGA, LabVIEW offers generous profitability changes that enable users to center around their calculations, not the complexity of their design. LabVIEW's broad gathering of FPGA IP helps users reach a speedier arrangement in case they are hoping to execute a totally new calculation, or they simply need to perform regular assignments continuously. LabVIEW FPGA incorporates many exceedingly enhanced capacities intended for use with fast I/O. If a user cannot discover what they are searching for in LabVIEW, IP is additionally accessible through the online network, NI Alliance Partners, and Xilinx.

The NI 6585B Digital I/O Adapter Module for FlexRIO comes with IDLs that are essential building blocks for basic tasks users might need to perform on the FPGA to spare significant time amid improvement. The most significant IDLs are the Streaming IDLs, which give stream control to DMA exchanges of information to the host, the DSP IDL which incorporates profoundly advanced capacities for regular signal handling tasks, and the Basic Elements IDL which abstracts ordinary capacities like counters and latches. Numerous libraries also contain capacities that keep running on the CPU and interface with their relating FPGA partners.

ModelNI-6585B
ManufacturerNational Instruments
Part Number784060-01
TypeDigital I/O Adapter Module for FlexRIO
Bidirectional Digital Channels32
Maximum Clock Rate200 MHz
Maximum Data Rate300 Mbits/s
Dimensions5.1 x 0.8 x 4.7 in.
Weight10 oz.
WarrantyOne Year Warranty
NI-6585B ManualUser Manual and Maintenance Manual Available for Download
PriceContact a sales representative for a quote.

National Instruments NI-6585B Frequently Asked Questions



Question: What type of signaling is possible with the NI-6585B?



Answer: The NI-6585B can perform differential signaling.



Question: What is the power-up state of the NI 6585B?



Answer: The power-up state of the NI 6585B is 100 Ω differential impedance with the drivers disabled.



Question: What are the differential generation voltage levels for the NI-6585B?



Answer: The differential generation voltage levels for the NI-6585B are 247 mV minimum and 454 mV maximum.



Question: What is the maximum data rate for the NI 6585B?



Answer: The maximum data rate for the NI 6585B is 200 Mbit/s single rate (SDR) and 300 Mbit/s double data rate (DDR).
