National Instruments PXI-6225 Multifunction I/O Module

The PXI-6225 (Part number: 779296-01) Multifunction I/O Module from the M Series by National Instruments has 40 differential or 80 single ended analog input channels, 16 bits resolution, 250 kS/s maximum sample rate, two analog output channels, and 24 total digital I/O/PFI channels. There are a few main blocks in the analog input circuitry for the NI PXI-6225: the I/O connector, ground-reference settings, instrumentation amplifier (NI-PGIA), and mux. The I/O connector permits the user to link analog input signals to the module. Next, the ground-reference settings circuitry decides between referenced single-ended, differential, and non-referenced single-ended input modes. The NI-PGIA is a measurement and instrument class amplifier that decreases settling times for all input ranges; preciseness can be sustained even while sampling numerous channels quickly. Lastly, the multiplexers (mux) can route a single AI channel at once to the ADC by way of the NI-PGIA.

The National Instruments PXI-6225 Multifunction I/O Module can also be linked to floating signal sources, such as optical isolators, thermocouples, isolation amplifiers, transformers, and battery-powered devices. If the input signal is less than 1 V, the signal leads go through loud atmospheres, the leads linking the signal to the device are longer than 10 feet, or two analog input channels are accessible for the signal, then differential links should be utilized with floating signal sources. On the other hand, if the input signal is higher than 1 V or the leads linking the signal to the device are smaller than 10 feet, then non-referenced single-ended (NRSE) links should be utilized with floating signal sources.

PXI-6225 Mature Status has been announced by National Instruments, but the module will still be available for purchase and repairs by Apex Waves.

ModelPXI-6225 (779296-01)
ManufacturerNational Instruments
SeriesM Series
TypeMultifunction I/O Module
Analog Input Channels80 single-ended and 40 differential
Sampling Rate250 kS/s maximum
Analog Input Resolution16 bits
WarrantyOne Year Warranty
PXI-6225 ManualUser Manual and Maintenance Manual Available for Download
PriceContact a sales representative for a quote.

National Instruments PXI-6225 Frequently Asked Questions



Question: What software can be used with the PXI 6225 NI?



Answer: The PXI 6225 NI can be used with NI-DAQmx and SignalExpress LE data-logging software.



Question: What is the recommended calibration interval for the NI PXI-6225?



Answer: The NI PXI-6225 has a recommended one year calibration interval.



Question: How are you able to use the NI PXI 6225 to test?



Answer: Yes, for test on the NI PXI 6225, you can use 16-bit, 250 kS/s analog inputs and 1 MHz digital line signal conditioning for applications including data logging and sensor measurements.
