FW-7344
Modular Systems > National Instruments > NI-73xx Series
| Description: | FW-7344, 4 Axes, 9 to 25 VDC, Stepper/Servo Motion Controller |
Need an Official Quote?
Or speak to a sales representative for additional information:
Phone:1-800-915-6216
Email:sales@apexwaves.com
National Instruments FW-7344 Stepper/Servo Motion Controller
The FW-7344 (Part Numbers: 186839C-01, 778113-01) is a Stepper/Servo Motion Controller. This Motion Controller is developed by a popular manufacturer named National Instruments. The FW-7344 is part of the NI-7340 family of Motion Controllers by NI. The FW-7344 functions with the NI-Motion driver software. This Motion Controller can be operated with tools like LabWindows, LabVIEW, and NI Motion Assistant as recommended by National Instruments. The NI FW-7344 can also be used with Visual Basic and C/C++ software. The FW-7344 is compatible with operating systems such as Windows XP/NT/2000.
The NI FW-7344 is designed as a mid-range motion product. This Motion Controller can be used for simple and complex motion applications as recommended by the developer. The FW-7344 is easy to use and operate for IEEE-1394 modules. The National Instruments FW-7344 is manufactured with both servo as well as stepper motor functionalities to be used for 1394 bus PCs. This Motion Controller is configured for utilizing straight-line vector moves as well as point-to-point stepper motor applications.
The NI FW-7344 is configured with 4 axes by assigning each axis with servo or stepper style of configuration. This Motion Controller is updated with 62 μs for the PID loop controller. The FW-7344 functions with a quadrature encoder or with feedback analog capabilities. The FW-7344 is characterized by blended motion profiles and two/three-dimensional interpolation with electronic gearing. The National Instruments FW-7344 Motion Controller can operate within 0 to 55 °C temperature range.
Associated Part Numbers: 186839C-01, 778113-01
| Model | FW-7344 |
|---|---|
| Manufacturer | National Instruments |
| Part Number | 778113-01, 186839C-01 |
| Type | Stepper/Servo Motion Controller |
| Axes | 4 |
| Power Consumption | 30 W, maximum |
| Voltage Range | 9 to 25 VDC |
| I/O Connectors | 68-pin female high-density VHDCI type |
| Driver Software | NI-Motion |
| Dimensions | 12.1 by 10.0 by 1.7 in. |
| Warranty | Three Year Warranty |
| FW-7344 Manual | User Manual and Maintenance Manual Available for Download |
| Price | Contact a sales representative for a quote. |
National Instruments FW-7344 Frequently Asked Questions
Question: What does a dim Power LED on the FW-7344 indicate?
Answer: A dim power LED indicates that the controller is not connected to an active 1394 port but is still receiving power.
Question: How does the RTSI bus connect to compatible devices?
Answer: The RTSI bus of the FW-7344 is connected with an external 14-pin shielded cable
Question: What is the storage temperature of the FW-7344?
Answer: The storage temperature of the FW-7344 is –20 to 70 °C
FW-7344 PDF Manuals
7344 7334 HARDWARE USER MANUAL.PDF
ARCHIVED 7344 HARDWARE USER MANUAL.PDF
ARCHIVED FLEXMOTION RELEASE NOTES.PDF
ARCHIVED FLEXMOTION SOFTWARE REFERENCE MANUAL.PDF
ARCHIVED FLEXMOTION SOFTWARE RELEASE NOTES.PDF
ARCHIVED RELEASE NOTES FLEXMOTION VI LIBRARY.PDF
MOTION CONTROL 7344 7334 HARDWARE USER MANUAL.PDF
