PXI-7330

Modular Systems > National Instruments > NI-73xx Series

Part Number PXI-7330
Manufacturer/Brand National Instruments
Description National Instruments PXI-7330 Stepper Motor Controller- 4 MHz maximum pulse rate

Speak to a sales representative for pricing & lead time:


National Instruments PXI-7330 Stepper Motor Controller

The NI PXI-7330 Stepper Motor Controller utilizes the NI-Motion driver. The benefit of this is if the user’s application needs changes later, they can undoubtedly update their equipment without changing the code. The user can also exploit any firmware refreshes with the field-upgradable firmware. Like other NI Motion controllers, the NI PXI-7330 controller offers intense capacities with its two data protection and machine vision functions. This model is a standout amongst the most effective, offering an RTSI bus or PXI trigger that the user can utilize straightforwardly without additional wiring and without bandwidth on the host bus. A NI PXI-7330 is perfect when utilizing stepper engines for applications where just basic movement is required.

Multi-stepping is incorporated in this model like dynamic smoothing. This is similar to dynamic smoothing, with the exception of being a significantly more aggressive utilization of the channel. Ordinarily, it results in a filter that starts to roll off two octaves underneath the resounding frequency. This is expected for use with coarse resolution (full/half-step input pulses) to smooth large steps into a continuous train of micro-steps and may give smoother movement, relying upon the motion application. The user can disable multi-stepping if they are not utilizing full or half digital resolution.

Dissimilar to other low-cost motion controllers, the PXI 7330 controller has an assortment of effective highlights including:

• Linear interpolation for coordinating multiple axes.

• Real-time framework integration for directly communicating with data acquisition or image acquisition boards

• High-execution stepper generation for guaranteeing smooth-motion at high speeds

• Up to 4 axes of stepper motion

ModelPXI-7330
ManufacturerNational Instruments
TypePXI Stepper Motor Controller
Maximum Update Rate62.5 us/axis
Trigger Inputs4
Voltage Range0 to 5 V
Dimensions6.3 x 3.9 in.
Weight6 oz.
WarrantyOne Year Warranty
PXI-7330 ManualUser Manual and Maintenance Manual Available for Download
PriceContact a sales representative for a quote.

National Instruments PXI-7330 Frequently Asked Questions



Question: How many analog input are on the NI PXI-7330?



Answer: There are 8 multiplexed, single ended analog inputs on the NI PXI-7330.



Question: What type of I/O connector is on the PXI 7330?



Answer: The PXI 7330 has two 68-pin female high-density VHDCI type I/O connectors.



Question: What is the resolution of the analog inputs on the PXI-7330?



Answer: The analog inputs on the PXI-7330 have 12 bits resolution.



Question: What type of motion I/O does the PXI-7330 have?



Answer: The PXI-7330 has quadrature, incremental, single ended motion I/O.

PXI-7330 Technical Specifications:


Manufacturer:National Instruments
Model:PXI-7330
Type:PXI Stepper Motor Controller
Repair Evaluation:$150

Why Buy From Apex Waves

Delivery: UPS, FedEX and DHL – Free UPS Ground on all orders
Overnight, Next Day Air or Expedited shipping options available
International delivery available
Same day shipping for in-stock on location
Warranty: All parts new, new surplus, used or reconditioned are covered by Apex Waves 1 Year Warranty
Returns: No hassle return policy.
Dedicated customer service team.
Payment:
Quick Quotes: Receive Price & Availability Today!
Calibration: Ask About Our Tiered Calibration Levels
Option & Modules: Confirm Your Requirements or Versions
Repair: Cost & Lead Time Available Upon Request for Service
