PXI-7340

Modular Systems > National Instruments > NI-73xx Series

Part Number PXI-7340
Manufacturer/Brand National Instruments
Description National Instruments PXI-7340 PXI Motion Controller with 63 ms watchdog timeout
In Stock - Ships Today
In Stock | Ships 3-5 Days

Speak to a sales representative for pricing & lead time:


National Instruments PXI-7340 Motion Controller

With the NI PXI-7340 Motion Controller, the user can perform as many as four axes of synchronous, coordinated motion control in a preemptive, multitasking, constant condition. This model offers progressed double-processor architecture that uses a 32-bit CPU combined with a digital signal processor (DSP) and custom FPGAs to give this Motion Controller superior abilities. The FIFO bus interface and intense capacity set give fast communications, while off-loading complex motion capacities from the host PC for optimized framework execution.

The NI PXI-7340 Motion Controller utilizes the DSP for all closed-loop control, including position tracking, PID closed-loop control computation, and motion trajectory generation. The DSP chip is supported by custom FPGAs that perform the rapid encoder interfacing, position catch and breakpoint functions, motion I/O processing, and stepper pulse generation for hard real-time functionality. The inserted CPU in this model runs to multitasking, constant working framework and handles host communications, command processing, multi-axis interpolation, error handling, general-purpose digital I/O, and overall motion framework integration capacities.

The embedded firmware depends on an installed RTOS piece and gives ideal framework execution in different motion applications. Motion tasks are organized. Task execution order relies upon the need of each task, the condition of the whole motion framework, I/O or other framework events, and the real-time clock.

The NI PXI-7340 Motion Controller direction generators figure the quick position charge that controls increasing speed and speed while it moves the hub to its objective position. Contingent upon how the user designs the hub, this order is then sent to the PID servo circle or stepper beat generator.

If you are interested in this model and you want to learn more about its options, specifications, and special features, the manual can be downloaded from apexwaves.com.

ModelPXI-7340
ManufacturerNational Instruments
TypePXI Motion Controller
Maximum Update Rate62.5 us/axis
Analog Inputs8
Analog Outputs4
Dimensions6.3 x 3.9 in.
Weight6 oz.
WarrantyOne Year Warranty
PXI-7340 ManualUser Manual and Maintenance Manual Available for Download
PriceContact a sales representative for a quote.

National Instruments PXI-7340 Frequently Asked Questions



Question: What is the maximum working voltage of the PXI-7340?



Answer: The PXI-7340 has a channel-to-earth maximum working voltage of 12 V, Category I and a channel-to-channel maximum working voltage of 22 V, Category I.



Question: How many digital I/O ports are on the NI PXI-7340?



Answer: There are four, 8-bit digital I/O ports on the NI PXI-7340.



Question: What type of input/output coupling does the PXI 7340 have?



Answer: The PXI 7340 has DC input/output coupling.



Question: What is the watchdog timeout on the PXI-7340?



Answer: The watchdog timeout on the PXI-7340 is 63 ms.

PXI-7340 Technical Specifications:


Manufacturer:National Instruments
Model:PXI-7340
Type:PXI Motion Controller
Repair Evaluation:$150
