PCI-8511

4.5/5 | 20 ratings

Modular Systems > National Instruments > PCI CAN Interfaces

Part Number PCI-8511
Manufacturer/Brand National Instruments
Description: PCI-8511, 1-Port, CAN Interface Device
In Stock | Ships in 5-10 Days
Fast Quote
Quoted Price
Lowest Price Guarantee
2-3 Year Warranty Included
Free Ground Shipping
  Get Pricing
2 year warrantyRefurbished
*What is Refurbished?
Quoted Price
Fully tested
2yr warranty
  Get Pricing

Need an Official Quote?



Or speak to a sales representative for pricing & lead time:


National Instruments PCI-8511 CAN Interface Device

The National Instruments PCI-8511 (Part Number: 780682-01) functions admirably in functions that need rapid ongoing control for many coverings and CAN signals, like the case of the equipment on top of it reproduction, quick prototyping of control, bus checking, automation control, and more. This model has an NI-XNET driver that controls the DMA and allows the inner processor to exchange outlines and CAN signals between the program and the interface without intruding into the CPU.

The NI-XNET interface unites the execution related with low-level microcontroller programming and the intensity of Windows and LabVIEW Real-Time OS advancement. The patent-pending NI-XNET gadget driven DMA motor decreases framework idleness for PC-based CAN, LIN, and FlexRay interfaces, from milliseconds to microseconds.

The driver-level signal Database motor and packaged NI-XNET utilities decreases tedious casing-to-flag interpretation while keeping up top execution. Support for industry-standard CAN, LIN, and FlexRay flag database positions, including FIBEX, CANdb (.DBC), LDF, and NI-CAN NCD, rearranges NI-XNET reconciliation into implanted system outline work processes. With equipment quickened outlines, NI-XNET gadgets offload dull preparing from the host framework, leaving more CPU time for executing models and performing different assignments. NI-XNET LIN gadgets likewise offer equipment planned booking, leaving more CPU time for different undertakings. NI RTSI synchronization bolster empowers NI-XNET interfaces to coordinate and synchronize with other NI items, including information securing, PXI secluded instrumentation, vision, and movement.

ModelPCI-8511
ManufacturerNational Instruments
Part Number780682-01
TypeCAN Interface Device
Ports1
TransceiverNXP TJA1054A or TJA1055T
CAN Physical LayerLow-Speed/Fault-Tolerant CAN
Maximum Baud Rate125 Kb/sec
Minimum Baud Rate10 Kbps
Trigger Lines7 Input/Output
Clock Lines1 Input/Output
I/O Connector9-pin Male D-SUB For Each Port
I/O CompatibilityTTL
Power Requirements+5 VDC, +3.3 VDC -- 640 mA, 940 mA
Dimensions4.2 in. x 6.6 in.
Weight0.22 lb.
Software DriverNI‑XNET
WarrantyOne Year Warranty
PCI-8511 ManualUser Manual and Maintenance Manual Available for Download
PriceContact a sales representative for a quote.

  PCI-8511 PDF Manuals

Driver Downloads for PCI-8511






OS Compatibility:
Win XP 32-bit, Win 7 32-bit, Win 10 32-bit

 Download Version


Why Buy From Apex Waves:

Apex Waves Youtube Video


Delivery:
UPS, FedEX and DHL – Free Fedex Ground on all orders
Overnight, Next Day Air or Expedited shipping options available
International delivery available
Same day shipping for in-stock on location
Warranty: All of our products are covered by our Apex Waves Warranty.
3 Year Warranty - New Surplus Parts
2 Year Warranty - Refurbished Parts
Returns: No hassle return policy.
Dedicated customer service team.
Payment:
Quick Quotes: Receive Price & Availability Today!
Calibration: Ask About Our Tiered Calibration Levels
Option & Modules: Confirm Your Requirements or Versions
Repair: Cost & Lead Time Available Upon Request for Service
Repair Evaluation: $150
