Part Number PCI-8513-2
Manufacturer/Brand National Instruments
Description: PCI-8513/2, 2-Port, CAN Interface Device
In Stock | Ships Today
Fast Quote
Quoted Price
Lowest Price Guarantee
2-3 Year Warranty Included
Free Ground Shipping
  Get Pricing
2 year warrantyRefurbished
*What is Refurbished?
Quoted Price
Fully tested
2yr warranty
  Get Pricing

Need an Official Quote?


*Most customers receive their price in about 15 minutes.

Or speak to a sales representative for pricing & lead time:


National Instruments PCI-8513/2 CAN Interface Device

The PCI-8513/2 (Part number: 780684-02) is a 2-port, programming selectable controller area network (CAN) Interface Device. All NI-XNET PCI interfaces highlight a NI RTSI synchronization connector for steering synchronization motions between NI RTSI-empowered boards. To synchronize signals with other NI RTSI-empowered boards, utilize RTSI strip links. All NI-XNET PXI interfaces course RTSI signals over the PXI timing and synchronization bus situated in the PXI backplane. The NI PCI-8513/2 interface includes front-panel sync connectors for directing planning and synchronization signals to outside gear. All NI-XNET C Series interfaces in a NI CompactDAQ or NI CompactRIO case naturally share a typical timebase with different modules in the suspension.

With the PCI-8513/2 CAN Interface Device, the user can choose each port exclusively on one of the accompanying handsets: fast, low-speed/fault-tolerant, or single wire. When a handset is chosen, it associates its locally available handsets to the port and carries on the same as a dedicated interface. Programming selectable interfaces are perfect for applications that require interfacing with different sorts of CAN systems, such as creation test, check and approval, and adaptable equipment insider savvy test systems. The FlexRay physical layer on PXI and PCI NI-XNET interfaces is inside fueled. All things considered, there is no compelling reason to supply bus control. The COM stick fills in as the reference ground for the bus signals. For all XNET gadgets, the end is programming selectable. XNET gives the choice of 80 between Bus Plus and Bus Minus or no end. The user cannot set end for channel A and channel B freely.

ModelPCI-8513/2
ManufacturerNational Instruments
Part Number780684-02
TypeCAN Interface Device
Ports2
TransceiverTJA1054A, 2 x TJA1041, 2 xAU5790
CAN Physical LayerSoftware-Selectable/FD
Maximum Baud Rate125 kbits/s, 8 Mbit/s, 83.3 kbits/s
Minimum Baud Rate40 kbits/s, 33.3 kbits/s
Trigger Lines7 Input/Output
Clock Lines1 Input/Output
I/O CompatibilityTTL
CAN_H, CAN_L Bus Lines Voltage-27 VDC to +40 VDC
I/O Connector2 x 9-Pin Male D-sub
Power Requirements+5 VDC, +3.3 VDC -- 640 mA, 940 mA
Dimensions4.2 in. x 6.6 in.
Weight0.22 lb.
Software DriverNI‑XNET, NI-CAN
WarrantyOne Year Warranty
PCI-8513/2 ManualUser Manual and Maintenance Manual Available for Download
PriceContact a sales representative for a quote.

National Instruments PCI-8513/2 Frequently Asked Questions



Question: How do I identify the PCI NI-XNET hardware revision for the NI PCI-8513/2?



Answer: To identify the PCI NI-XNET hardware revision for the NI PCI-8513/2, refer to the 198980-4XL text on the green label in the top left corner of the secondary side of the board.



Question: Which single wire transceiver is recommended for the PCI-8513/2?



Answer: The PCI-8513/2 uses the ON Semiconductor NCV7356 single-wire transceiver.



Question: Does the PCI-8513/2 work well for high-speed manipulation of multiple CAN frames?



Answer: The PCI-8513/2 is ideal for real-time, high-speed manipulation of hundreds of CAN frames and signals, including hardware-in-the-loop simulation.
