National Instruments PXIe-4322 PXI Analog Output Module

The PXIe-4322 (Part Numbers: 782878-01) by National Instruments is a channel-to-channel isolated analog output module designed for precise, simultaneous voltage and current outputs. It integrates signal conditioning and 16-bit digital-to-analog converters (DACs) on a single device, optimizing space and enhancing measurement accuracy. This module is especially well-suited for automotive applications due to its small size.

With its 16-bit R-2R DACs installed in each of its 8 analog output channels, the PXIe-4322 provides high-resolution output with a maximum DNL of ±1 LSB and INL of ±4 LSBs. It is capable of delivering +/-16 V at 20 mA in voltage mode or +/-20 mA in current mode, operating at up to 250 kS/s per channel. It is noteworthy that it can sink and source current and that it functions in all four quadrants in current mode. The PXIe-4322 guarantees safety and dependability in measurement setups with its 300 Vrms CAT II channel-to-channel and channel-to-earth isolation.

The voltage channels can be stacked up to 128 V per module or up to 300 V with an external offset thanks to its isolation capability. In order to obtain greater current outputs, channels can also be connected in series, which increases application versatility. The NI-DAQmx driver makes it simple to program the module, which can be used for hardware-timed single-point operations and multidevice tasks. It enables smooth integration into current systems because it closely synchronizes with more than 1,500 PXI I/O instruments as part of the PXI platform.

The PXIe-4322 ensures high-speed data transmission by offering dedicated data throughput of up to 250 MB/s per device through the use of PXI Express technology. It provides differential signaling and a 100 MHz differential system clock, among other sophisticated timing and synchronization features. The module offers versatility in system setup as it may be used with both x1 and x4 PXI Express or PXI Express hybrid slots. It further simplifies data transfer procedures by including a single DMA channel for analog input.

The PXIe-4322, which offers screw-terminal connectivity for simple rewiring and channel stacking, pairs with the NI TB-4322 front-mount terminal block in order to facilitate easy connectivity. The ability to hot-swap terminal blocks and have them recognized immediately by software makes maintenance and troubleshooting easier.

ModelPXIe-4322
Part Number782878-01
ManufacturerNational Instruments
TypePXI Analog Output Module
Analog Output Channels8
Maximum Update Rate250 kS/s
Analog Output Resolution16 bits
Dimensions6.3 x 3.9 in.
Weight5.7 oz.
WarrantyThree Year Warranty
PXIe-4322 ManualUser Manual and Maintenance Manual Available for Download
PriceContact a sales representative for a quote.

Associated part numbers for the PXIe-4322:

153917A-01L, 153917B-01L, 153917C-01L, 153917D-01L, 153917E-01L, 154229A-01L, 200036A-01, 200197A-01, 200269A-01, 200417A-01, 200718A-01, 782878-01

National Instruments PXIe-4322 Frequently Asked Questions

Question: What is the output current range of the PXIe-4322?

Answer: The output current range of the PXIe-4322 is -20 mA to 20 mA.



Question: How can the DAC on the NI PXIe-4322 be configured?

Answer: The NI PXIe-4322 DAC can be configured as a voltage output mode or a current output mode.



Question: Which terminal block can be used with the PXIe-4322?

Answer: The TB-4322 terminal block can be used with the PXIe-4322.



Question: What types of data transfers does the NI PXIe-4322 have?

Answer: The NI PXIe-4322 has DMA (scatter-gather) and programmed I/O data transfers.
