Part Number PXI-8250
Manufacturer/Brand National Instruments
Description: PXI-8250, 6-LED, System Monitoring Module
Lowest Price Guarantee
Fast Quote
Quoted Price
2-3 Year Warranty Included
Free Ground Shipping
  Get Pricing
2 year warrantyRefurbished
*What is Refurbished?
Quoted Price
Fully tested
2yr warranty
  Get Pricing

Need an Official Quote?


*Most customers receive their price in about 15 minutes.

Or speak to a sales representative for pricing & lead time:


National Instruments PXI-8250 PXI System Monitoring Module

The PXI-8250 (Part Number: 780316-01) 6 LED System Monitoring Module effectively controls the voltage, fan, and temperature status of PXI frameworks and reports it through an arrangement of LEDs on the front board of the module. The NI PXI-8250 can be utilized with the PXI-1042, PXI-1042Q or PXI-1045 case to distinguish and report issues in the chassis voltage rails, unusual temperature, or fan failure. The PXI-8250 additionally incorporates a relay that can be initiated when any of the parameters is outside the chassis task specification. With the PXI-8250, the user can screen the power utilization, fan speeds, and power supply levels of their NI PXI chassis at the same time. This data enables the client to accomplish a larger amount of system performance reliability. Once the principal set of information is handled, these status parameters will illuminate the main six LEDs on the front board. The LEDs light up green if the status parameter is in range or red if the parameter is out of range.

The NI PXI-8250 gives monitoring of the single intake thermistor located in the power supply shuttle of the PXI frame. The reading from the thermistor (0-50° C) is contrasted with the working scope of the case. All temperature estimations are accounted for in Celsius and are accurate to inside 1° C of the present admission temperature.

The PXI-8250 module enables the client to monitor the revolutions per minute (RPM) of all rear facing fans of a PXI chassis (two fans in an NI PXI-1042/1042Q and three fans in a NI PXI-1045), accurate to ± 50 RPM.

PXI-8250 Mature Status has been announced by National Instruments, but the module will still be available for purchase and repairs by Apex Waves.

ModelPXI-8250
Part Number780316-01
ManufacturerNational Instruments
TypePXI System Monitoring Module
LEDs6
CompatibilityPXI-1042, PXI-1042Q, PXI-1045
Connector8-pin 3.5 mm pitch, screw-flange connector
Dimensions5.25 x 0.8 in.
Weight5.29 oz.
WarrantyOne Year Warranty
PXI-8250 ManualUser Manual and Maintenance Manual Available for Download
PriceContact a sales representative for a quote.

National Instruments PXI-8250 Frequently Asked Questions



Question: What are the front panel dimensions of the PXI-8250?



Answer: The PXI-8250 front panel dimensions are 3U x 4 HP.



Question: What is the primary function of the NI PXI-8250?



Answer: The NI PXI-8250’s primary function is to monitor and report chassis voltage rail issues, chassis power shuttle fan failure, or out-of-range chassis intake temperature for the PXI-1045, PXI-1042, and PXI-1042Q.



Question: Which driver software should be used with the PXI-8250?



Answer: The driver software for the PXI-8250 is the NI System Monitor 1.1 driver software.



Question: Which slot should the NI PXI-8250 be installed in for the compatible Chassis?



Answer: The NI PXI-8250 should only be installed in the furthest right slot for the compatible Chassis. This means slot 8 of the PXI-1042/1042Q or slot 18 of the PXI-1045.
