National Instruments PXI-7854 PXI Multifunction Reconfigurable I/O Module

The PXI-7854 (Part Number: 780342-01) shows a favorable position of the FPGA Module, which is a parallel execution of square outline tasks in a FPGA VI. Bits of the square chart that do not rely upon different segments execute in parallel on the FPGA gadget. For instance, various free While Loops on a square outline each have autonomous bits of equipment. In this way, the different free While Loops run on the FPGA gadget. The FPGA Module enhances the usefulness of LabVIEW arrangements. For instance, the user can outline FPGA VIs that enable the FPGA gadget to work freely of whatever is left of the framework. The user can make strong FPGA VIs that use the capacity to work freely and keep on running regardless of whether the host PC—the PC that controls and screens the FPGA gadget—crashes. Besides, the user can plan the FPGA VI to store information on the FPGA until the host PC can recover the information.

Utilize Interactive Front Panel Communication between the FPGA gadget and the host PC to control and test VIs running on the FPGA gadget. Subsequent to downloading and running the FPGA VI, keep LabVIEW open on the host PC to show and collaborate with the front board of the FPGA VI. The user can also utilize an RT focus as the host PC. The RT target can utilize Programmatic FPGA Interface Communication to speak with the FPGA gadget. Then, the user can utilize a Windows PC to communicate with the RT target. The adaptability of FPGA gadgets incorporates well with LabVIEW Real-Time Module applications, such as control and equipment tuned in reproductions, which require a lot of determinism.

PXI-7854 Mature Status has been announced by National Instruments, but the module will still be available for purchase and repairs by Apex Waves.

ModelPXI-7854
ManufacturerNational Instruments
SeriesR Series
Part Number780342-01
TypePXI Multifunction Reconfigurable I/O Module
FPGA TypeVirtex-5 LX110
Analog Inputs8 (16 Bits, 750 kS/s)
Analog Outputs8 (16 Bits, 1 MS/s)
Number of Flip-flops69,120
Number of 25 × 18 Multipliers64
Embedded Block RAM4,608 kbits
Digital I/O96 (TTL)
Number of DMA Channels3
Timebase40, 80, 120, 160, or 200 MHz
I/O Connectors3 68-pin Female High-Density VHDCI
Power Requirements+3.3 VDC, 5 VDC, 12 VDC, - 12 VDC - 843 mA, 484 mA, 0.5 A, 0.25 A
Dimensions6.3 in. by 3.9 in.
Weight0.33 lb.
Software DriverNI-RIO
WarrantyOne Year Warranty
PXI-7854 ManualUser Manual and Maintenance Manual Available for Download
PriceContact a sales representative for a quote.
