National Instruments PXIe-7847 PXI Multifunction Reconfigurable I/O Module

Featured with 512 MB DRAM and a Kintex-7 160T FPGA, the NI PXIe-7847 (Part Numbers: PXIe-7847R and 784144-01) is a Multifunction Reconfigurable I/O Module from the R Series by National Instruments. This module is designed for PXI Express and comes with 8 AI, 8 AO, and 48 DIO. The NI PXIe-7847 offers connectors for eight analog input channels. In addition to AI+ and AI- pins, each analog input channel has an AIGND pin, to which both differential voltage or single-ended signals can be connected. The AISENSE pin is used to connect non-referenced single-ended signals.

The PXIe-7847 has a Digital I/O Connector 0 that contains 16-low speed DIO channels. Another interface, Connector 1 is also on the module with 32 high-speed DIO channels. Both connectors have selectable logic levels. In its default configuration, the NI PXIe-7847 uses pull-down resistors to initiate the DIO channels as “input low”. However, users can have their desired power-on state configured across all DIO lines. In this module, protected buffers are utilized for facilitating secure connections between the Kintex-7 160T FPGA and digital input/output channels. The integrated protection scheme offers adequate protection against overvoltage, overcurrent, and under-voltage conditions.

This Multifunction Reconfigurable I/O Module offers direction control of digital input/output channels on a per channel basis and programmable voltage selection on the per connector basis. As far as its physical characteristics are concerned, the PXIe-7847 weighs around 171.2 g, with dimensions of 18.5 cm × 17.3 cm × 3.6 cm. This module is compatible with PXI Express and PXI Express Hybrid slots.

ModelPXIe-7847
Part Number784144-01
ManufacturerNational Instruments
TypePXI Multifunction Reconfigurable I/O Module
FPGAKintex-7 160T
Maximum Sample Rate500 kS/s
Analog Input Channels8
Dimensions7.3 x 6.8 x 1.4 in.
Weight6.04 oz.
WarrantyOne Year Warranty
PXIe-7847 ManualUser Manual and Maintenance Manual Available for Download
PriceContact a sales representative for a quote.

National Instruments PXIe-7847 Frequently Asked Questions



Question: How many analog output channels does the PXIe-7847 have?



Answer: The PXIe-7847 has 8 analog output channels.



Question: What are the power requirements for the NI PXIe-7847?



Answer: The NI PXIe-7847 has power requirements of 3 A at +3.3 V and 2 A at +12 V.



Question: What is the maximum update rate of the PXIe-7847?



Answer: The maximum update rate of the PXIe-7847 is 1 MS/s.



Question: What is the analog input voltage range of the NI PXIe-7847?



Answer: The analog input voltage range of the NI PXIe-7847 is -1 V to 1 V, -2 V to 2 V, -5 V to 5 V, -10 V to 10 V.
