National Instruments SCXI-1314 Universal Strain Terminal Block

The SCXI-1314 (Part Number: 777687-14) is created for use with the SCXI-1520 universal strain/bridge module. This combination allows the user to easily link strain gauges via screw terminals. The 88 screw terminals on this Terminal Block are configured in eight groups, with 11 screw terminals in each group. Every group corresponds to a channel on the SCXI-1520 module. Every channel input has screw terminals that join to the inputs of the SCXI-1520. There are also two precision 100 kΩ shunt calibration resistors and a precision quarter-bridge completion resistor.

The SCXI 1520 module has relays that switch the resistors in and out of the input circuit to give shunt calibration and quarter-bridge completion. The quarter-bridge completion resistor has a factory default value of 350 Ω to utilize with a 350 Ω strain gauge. The resistors are put in sockets on the Terminal Block, so the user can effortlessly replace them with resistors appropriate to the user’s certain strain gauge. If the user’s application demands a 120 Ω strain gauge, then they can utilize eight 120 Ω resistors.

There are several items required to install the SCXI-1314 Terminal Block. Firstly, SCXI chassis is needed. The user also needs the SCXI-1520 module, eight precision 120 Ω resistors for use in quarter-bridge completion circuits (dependent on application), a wire insulation stripper, a wire cutter, long-nose pliers, a 1/8 in. flathead screwdriver, Number 1 and 2 Philips-head screwdrivers, and the Installation Guide/User Manual for the SCXI-1314 and the SCXI-1520.

The SCXI-1314 is run using the NIDAQmx driver software which is compatible with software packages/application development environments (ADEs) such as LabVIEW, LabWindows/CVI, or Measurement Studio.

The NI device has a recommended operating temperature range of 0 to 50 °C, a storage temperature range of –20 to 70 °C, and a non-condensing relative humidity range of 10 to 90%. It is designed to comply with the following electrical equipment safety standards: IEC 61010-1, EN 61010-1, UL 61010-1, and CAN/CSA C22.2 No. 61010-1.

SCXI-1314 Obsolete Status has been announced by National Instruments, but the Terminal Block will still be available for purchase and repairs by Apex Waves.

The SCXI-1314 is available to be calibrated. While the recommended calibration period for individual parts varies, most parts should be calibrated either annually or every two years to ensure accuracy. If you need the SCXI-1314 calibrated, Apex Waves provides options. We offer high-quality NIST accredited calibrations through a 3rd party, with an average turnaround time of 1 to 2 weeks. When you order the SCXI-1314 with us, you can request basic (unaccredited) in-house calibration that will calibrate the part to the manufacturer specifications prior to being shipped. Call or email us today for more information about calibrating the SCXI-1314!

ModelSCXI-1314
Part Number777687-14
ManufacturerNational Instruments
TypeUniversal Strain Terminal Block
Screw Terminals88
Compatible ModuleSCXI-1520
Lead Spacing0.500 in.
Resistors120 Ω or 350 Ω
WarrantyThree Year Warranty
SCXI-1314 ManualUser Manual and Maintenance Manual Available for Download
PriceContact a sales representative for a quote.
