PXI-8231

Modular Systems > National Instruments > Serial Interface Devices

Part Number PXI-8231
Manufacturer/Brand National Instruments
Description PXI-8231 1-Port Ethernet Interface Module
In Stock - Ships Today
In Stock | Ships 3-5 Days

Speak to a sales representative for pricing & lead time:


National Instruments PXI-8231 Ethernet Interface Module

The NI PXI-8231 (Part numbers: 781752-01 and 781764-01 ) is an elite 1-Port Gigabit Ethernet Module for PXI frameworks with an Intel 82541PI Gigabit Ethernet controller. With 1000 Mbit/s Gigabit Ethernet, the user can accomplish a significant execution increment more than 100 Mbit/s Fast Ethernet, while maintaining compatibility with 10BASE-T and 100BASE-TX Fast Ethernet systems. The PXI-8231 can be used with NI-IMAQdx driver software.

The PXI 8231 offers genuine Performance Gains; Gigabit Ethernet hypothetically gives a 1000 Mbit/s transmission speed. However, 1000 Mbit/s approaches the breaking point of PCI bus transfer speed; thus, the greatest transmission speeds are framework specific. Variables such as the user’s CPU speed, other PCI traffic, and Ethernet network configuration determine execution may allow the user to achieve transmission speeds of 500 Mbit/s and reach paces of 800 Mbit/s. This remains five to eight times the execution of 100BASE-TX Fast Ethernet.

The NI PXI-8231 Ethernet Interface Module is completely compatible with Ethernet models and cabling. The user can utilize standard Category 5 Ethernet links and accomplish Gigabit Ethernet execution, given the majority of the conductor matches in the link are associated (4 sets x 250 Mbit/s per combine = 1000 Mbit/s). Also, the Gigabit Ethernet Module naturally identifies link extremity, so there is no compelling reason to swap between crossover and straight-through cabling for various system arrangements. The Gigabit Ethernet port switches between 10, 100, and 1000 Mbit/s modes, depending on the user’s system's capability as determined by the server speed, switch/router limit, and wiring limit.

ModelPXI-8231
Part Numbers781752-01, 781764-01
ManufacturerNational Instruments
TypeEthernet Interface Module
Ethernet Ports1
Ethernet Bandwidth1 Gbits/s
Camera InterfaceRJ-45
Dimensions6.3 x 3.9 in.
Weight4.9 oz.
WarrantyOne Year Warranty
PXI-8231 ManualUser Manual and Maintenance Manual Available for Download
PriceContact a sales representative for a quote.

National Instruments PXI-8231 Frequently Asked Questions



Question: What type of cameras does the PXI-8231 support?



Answer: The PXI-8231 supports GigE Vision cameras.



Question: Which devices/accessories are necessary to utilize the NI PXI-8231?



Answer: To use the NI PXI-8231, you need the PXI-8231 device, a GigE Vision Camera, an Ethernet cable, a PXI, PCIe, or CompactPCI computer with Microsoft Windows Vista/2000/XP with one slot minimum, and NI Vision Acquisition Software 8.2.1 or later.



Question: Which Ethernet networks is the PXI-8231 compatible with?



Answer: The PXI-8231 is compatible with 10BASE-T and 100BASE-TX Fast Ethernet networks.



Question: What is the difference between the two part numbers for the NI PXI-8231?



Answer: Part number 781764-01 is designed for LV RT 2009 and earlier, while part number 781752-01 is designed for Windows and LV RT.



PXI-8231 Technical Specifications:


Manufacturer:National Instruments
Model:PXI-8231 (781752-01)
Type:Ethernet Interface Module
Repair Evaluation:$150

Why Buy From Apex Waves

Delivery: UPS, FedEX and DHL – Free UPS Ground on all orders
Overnight, Next Day Air or Expedited shipping options available
International delivery available
Same day shipping for in-stock on location
Warranty: All parts new, new surplus, used or reconditioned are covered by Apex Waves 1 Year Warranty
Returns: No hassle return policy.
Dedicated customer service team.
Payment:
Quick Quotes: Receive Price & Availability Today!
Calibration: Ask About Our Tiered Calibration Levels
Option & Modules: Confirm Your Requirements or Versions
Repair: Cost & Lead Time Available Upon Request for Service
