PXI-8421-2

Modular Systems > National Instruments > Serial Interface Devices

Part Number PXI-8421-2
Manufacturer/Brand National Instruments
Description PXI-8421/2 2-Port RS-485 Interface

Speak to a sales representative for pricing & lead time:


National Instruments PXI-8421/2 RS-485 Interface

Featured with hyperthreading and multiprocessor capabilities, the National Instruments PXI-8421/2 is a high-performance, Serial RS-485 Interface for high-speed communications. This model features universal PCI and is fully compatible with a standard PC serial port. The National Instruments PXI-8421 is fully Plug-and-Play compatible with Windows 2000/9x; thus, it can be operated in a switchless configuration. This module is capable of handling interrupt sharing between ports and RTS/CTS hardware handshake lines. The NI PXI-8421/2 has two ports (Part Number: 777735-02), but there are also 4 and 8 port configurations available.

The 2-port version incorporates DB-9 male connectors. When purchasing this module in a 4-port configuration, the user can order cables that can be used for the conversion of phone jacks to either DB-25 or DB-9 male connectors. In 8-port configuration, the NI PXI-8421 comes equipped with an SCSI 68-pin interface.  This Serial Interface offers up to 460.8 (kb/s) maximum transfer rate, has a 64 (B) FIFO, and fully supports the LabVIEW Real-Time software.

The NI PXI 8421/2 features an advanced memory-mapping feature that allows the user to connect to more serial devices without encountering resource conflicts. Since this Interface Module is fully compatible with both 3.3 V and 5 V signaling environments, this board can work in a broad range of PCs. This module can easily be installed as a standard serial port from numerous applications, such as Visual Basic, Visual C++, and Excel. The National Instruments PXI-8421/2 is compatible with any package that uses the Microsoft Win32 Serial API.

PXI-8421/2 Obsolete Status has been announced by National Instruments, but will still be available for purchase and repairs by Apex Waves.

ModelPXI-8421/2
Part Number777735-02
ManufacturerNational Instruments
TypeRS-485 Serial Interface
Maximum Transfer Rate460.8 kb/s
Data Line ESD Protection (HBM)2 kV
FIFO Size64 B
Dimensions6.3 x 3.9 in.
I/O ConnectorDB-9 male
WarrantyOne Year Warranty
PXI-8421/2 ManualUser Manual and Maintenance Manual Available for Download
PriceContact a sales representative for a quote.

National Instruments PXI-8421/2 Frequently Asked Questions



Question: What is the maximum current for the PXI-8421/2 at +5 VDC?



Answer: The maximum current for the PXI-8421/2 at +5 VDC is 750 mA.



Question: What is the optical isolation provided by the NI PXI-8421/2?



Answer: The NI PXI-8421/2 provides an optical isolation of 2000 V.



Question: Is the PXI-8421/2 an isolated model?



Answer: No, the PXI-8421/2 is not isolated.



Question: Which serial interfaces are on the NI PXI-8421/2?



Answer: The NI PXI-8421/2 has RS-485/RS-422 interfaces.

PXI-8421-2 Technical Specifications:


Manufacturer:National Instruments
Model:PXI-8421/2
Part Number:777735-02
Type:RS-485 Interface
Repair Evaluation:$150
