PXI-8433-4

Modular Systems > National Instruments > Serial Interface Devices

Part Number PXI-8433-4
Manufacturer/Brand National Instruments
Description PXI-8433/4 4-Port RS-485/RS-422 Interface
In Stock - Ships Today
In Stock | Ships 3-5 Days

Speak to a sales representative for pricing & lead time:


National Instruments PXI-8433/4 RS-485/RS-422 Interface

The PXI-8433/4 (Part Number: 779539-01) 4 Port, Isolated, RS-485/RS-422, Serial Instrument Control Module is an asynchronous interface for communicating with instruments by means of serial ports. Depending on the platform, interfaces are accessible with as many as 16 ports and full Windows 2000/NT/XP/Me/9x plug-and-play compatibility, which gives the user the advantage of programmed setup for less demanding establishment and maintenance. The user can introduce and utilize these gadgets as standard serial ports from their current applications or with applications composed with NI-VISA.

Development environments, such as Visual Basic, Visual C++, and Excel, along with NI LabVIEW, LabWindows/CVI, Measurement Studio, and Lookout application programming items, can access the add-in serial ports by utilizing standard serial I/O capacities. The NI PXI-8433/4 incorporates an upgraded serial driver for enhanced execution, simple design, and access to the advanced transceiver control modes of the RS-485 interface.

The 4-port interface utilizes 10-position phone jacks, so each of the four connectors can exist on a single back panel. When purchasing a 4-port serial interface, the user can arrange links that change over the phone jacks to either DB-9 or DB-25 male connectors with standard pin assignments. In general, the user should arrange four converter links for each 4-port serial gadget. Note that a converter link is not intended to go the full distance from a 4-port serial interface specifically to the instruments. The most popular converter cables change over the 10-pin phone jack on a 4-port gadget to a similar DB-9 male connector, which can be found on a normal PC serial port. The association from this converter to the serial gadget uses the standard links utilized with the PC serial port.

ModelPXI-8433/4
Part Number779539-01
ManufacturerNational Instruments
TypePXI Serial Interface Module
Ports4
Supported Serial ProtocolRS-422, RS-485
Isolation TypePort-PC Isolation, Port-Port Isolation
Dimensions6.3 x 3.9 in.
Weight147 g.
WarrantyOne Year Warranty
PXI-8433/4 ManualUser Manual and Maintenance Manual Available for Download
PriceContact a sales representative for a quote.

National Instruments PXI-8433/4 Frequently Asked Questions



Question: What is the maximum cable length for the PXI-8433/4?



Answer: The PXI-8433/4 has a 30 m maximum cable length.



Question: What is the maximum serial transfer rate for the NI PXI-8433/4?



Answer: The maximum serial transfer rate for the NI PXI-8433/4 is 3,000,000 bps.



Question: Which operating systems is the PXI-8433/4 compatible with?



Answer: The PXI-8433/4 is compatible with Windows and LabVIEW Real-Time OS.

PXI-8433-4 Technical Specifications:


Manufacturer:National Instruments
Model:PXI-8433/4 (779539-01)
Type:RS-485/RS-422 Interface
Repair Evaluation:$150
