National Instruments PXI-8461/D DeviceNet Interface Module

Featured with a High-Performance Intel 80386EX microprocessor, the National Instruments PXI-8461/D (Part Number: 777709-01) is a DeviceNet Interface Module that includes a 1-port CAN hardware interface. This kit is offered with the NI-DNET software, which provides an API for complete access to any DeviceNet network. By design, the NI PXI-8461/D is a 3U size module, fully compatible with the CompactPCI industrial computer standard and the PXI modular instrumentation. This kit does not require interface cables since it comes with standard Combicon-style pluggable screw terminals for network connections.

The National Instruments PXI-8461/D is considered an ideal choice for PC-based control systems, embedded control systems, DeviceNet network management utilities, and for the prototyping of the DeviceNet Systems. This kit is fully compatible with all standard programming standards, such as Borland C/C++, Microsoft C/C++, Microsoft Visual Basic, LabWindows/CV, Lookout, etc. The 80386EX processor incorporated in this model offers an efficient operating environment for processing the DeviceNet protocol communications stack. For optimal reliability, this model is developed on Allen-Bradley’s Master Toolkit and is fully compatible with Allen Bradley winDNBT-16 architecture.

The software provided with the NI PXI-8461/D includes protocol firmware that works on the embedded 80386EX microprocessor, as well as the device drivers that professionals use for applications development. This CAN device handles information on the interface device directly. The NI CAN interfaces are designed in accordance with all DeviceNet specifications related to the physical layer, including bus-powered transceivers and 500 V optical isolation. The NI PXI-8461/D has a shared memory where 80386EX of the CAN interface stores the I/O variables of the networked devices.

PXI-8461/D Obsolete Status has been announced by National Instruments, but will still be available for purchase and repairs by Apex Waves.

ModelPXI-8461/D
Part Number777709-01
ManufacturerNational Instruments
TypeDeviceNet Interface Module
Ports1
Typical Current750 mA
Driver SoftwareNI-DNET
Dimensions6.3 x 3.9 in.
I/O ConnectorCombicon-style pluggable screw terminals
WarrantyOne Year Warranty
PXI-8461/D ManualUser Manual and Maintenance Manual Available for Download
PriceContact a sales representative for a quote.

National Instruments PXI-8461/D Frequently Asked Questions



Question: What is the difference between the PXI-8461/1 or PXI-8461/2 and the PXI-8461/D?



Answer: The difference between the PXI-8461/1 or PXI-8461/2 and the PXI-8461/D is that the PXI-8461/D is a DeviceNet Interface Module and comes with NI-DNET software, while the PXI-8461/1 and PXI-8461/2 are CAN Interface Modules with NI-CAN software.



Question: What standards is the PXI-8461/D compatible with?



Answer: The PXI-8461/D is compatible with the PXI modular instrumentation and the CompactPCI industrial computer standard.



Question: What type of microprocessor does the NI PXI-8461/D have?



Answer: The NI PXI-8461/D has an Intel 80386EX microprocessor.



Question: What is the specification for the optical isolation on the PXI-8461/D?



Answer: The optical isolation on the PXI-8461/D is 500 V.

PXI-8461-D Technical Specifications:


Manufacturer:National Instruments
Model:PXI-8461/D
Part Number:777709-01
Type:DeviceNet Interface Module
Repair Evaluation:$150

Why Buy From Apex Waves

Delivery: UPS, FedEX and DHL – Free UPS Ground on all orders
Overnight, Next Day Air or Expedited shipping options available
International delivery available
Same day shipping for in-stock on location
Warranty: All parts new, new surplus, used or reconditioned are covered by Apex Waves 1 Year Warranty
Returns: No hassle return policy.
Dedicated customer service team.
Payment:
Quick Quotes: Receive Price & Availability Today!
Calibration: Ask About Our Tiered Calibration Levels
Option & Modules: Confirm Your Requirements or Versions
Repair: Cost & Lead Time Available Upon Request for Service
