USB-8502

Modular Systems > National Instruments > Serial Interface Devices

Part Number USB-8502
Manufacturer/Brand National Instruments
Description USB-8502, 1 or 2-Port, USB CAN Interface Device

Speak to a sales representative for pricing & lead time:


National Instruments USB-8502 CAN Interface Device

The NI USB-8502 (Part Numbers: 784661-01 and 784662-01) is powered through the USB 2.0 High-Speed Bus Interface and does not require external power. This CAN Interface Device has either one or two ports. This device functions well in applications that require fast constant control of many CAN signals and casings, such as bus checking, robotization control, and more. In this model, there is a DMA motor that allows an interior processor to work. The USB-8502 NI is equipped with a standard Type A plug I/O connector and a 9-pin male D-SUB I/O connector. Utilizing the time when the signal outline is received, this model resamples the signal information to a waveform with a settled sample rate. This model commonly is utilized for synchronizing XNET information with DAQmx simple/computerized input channels.

The user can maintain a strategic distance from the loss of signal information by setting the session resample rate to a high rate. NI-XNET timestamps get casings to an exactness of 100 ns. In this way, if the user utilizes a resample rate of 1000000 (1 MHz), each edge's flag esteems are spoken to in the waveforms without loss of information. The user can pass this I/O name into a XNET Interface property hub to recover equipment data for the interface, such as the name and sequential number. The I/O name is a similar reference accessible from the XNET System property hub, which is utilized to peruse data for all XNET equipment in the framework.

ModelUSB-8502
ManufacturerNational Instruments
Part Numbers784661-01 and 784662-01
TypeCAN Interface Device
Ports1 or 2
USB I/O ConnectorStandard Type A plug
Bus InterfaceUSB 2.0 High-Speed
Dimensions1 Port: 3.30 in. x 4.05 in. x 0.98 in.
2 Ports: 3.65 in. x 4.05 in. x 0.98 in.
Weight1 Port: 7.30 oz.
2 Ports: 7.58 oz.
WarrantyOne Year Warranty
USB-8502 ManualUser Manual and Maintenance Manual Available for Download
PriceContact a sales representative for a quote.

National Instruments USB-8502 Frequently Asked Questions



Question: What is the difference between the two part numbers for the NI USB-8502?



Answer: The NI USB-8502 has a 1-port version which does not support external timing and triggering (Part Number: 784661-01) and a 2-port version which does support external timing and triggering (Part Number: 784662-01).



Question: What is the input voltage of the USB-8502 NI?



Answer: The USB-8502 NI has an input voltage of 4.5 V minimum, 5.25 V maximum.



Question: What is the length of the USB cable for the NI USB CAN 8502?



Answer: The NI USB CAN 8502 has a USB cable length of 2 m.

USB-8502 Technical Specifications:


Manufacturer:National Instruments
Model:USB-8502
Part Numbers:784661-01 and 784662-01
Type:CAN Interface Device
Repair Evaluation:$150

Why Buy From Apex Waves

Delivery: UPS, FedEX and DHL – Free UPS Ground on all orders
Overnight, Next Day Air or Expedited shipping options available
International delivery available
Same day shipping for in-stock on location
Warranty: All parts new, new surplus, used or reconditioned are covered by Apex Waves 1 Year Warranty
Returns: No hassle return policy.
Dedicated customer service team.
Payment:
Quick Quotes: Receive Price & Availability Today!
Calibration: Ask About Our Tiered Calibration Levels
Option & Modules: Confirm Your Requirements or Versions
Repair: Cost & Lead Time Available Upon Request for Service
