National Instruments PXIe-6361 PXI Multifunction I/O Module
The PXIe-6361 (Part Number: 781055-01) is a high-performance, 16-bit Multifunction I/O Module from NI. The NI PXIe-6361 is a complete package in a single PXI module. It offers analog I/O, digital I/O, and counter/timers. The PXIe-6361 enables the user to perform configurations and measurements easily. It is equipped with a NI-DAQmx driver and MAX configuration utility. The module delivers advanced timing functionality, independent timing engines, and triggerable measurement tasks.
The NI PXIe-6361 module has 16 single-ended or 8 differential analog input channels, two analog output channels, and 24 digital I/O lines. The resolution of analog inputs and outputs is 16 bits. The maximum channel sampling rate of the inputs ranges from 1.0 MS/s to 2.0 MS/s. The range of the output maximum channel sampling rate is 2.0 MS/s ~ 2.86 MS/s. There is no limit to the minimum channel sampling rate. The National Instruments PXIe-6361 Multifunction I/O Module has four 32-bit, 100 MHz counters. These counters are used for PWM, encoder, frequency, event counting, and triggering functionality.
The PXIe-6361 module has NI-STC3 timing and synchronization technology. It offers advanced timing and triggering. The module has one 68-pin female VHDCI connector. The module has a high-throughput PCI Express bus, a multicore-optimized driver, and application software. The PCI Express Bus offers a dedicated bandwidth up to 250 MB/s. The driver and software are supported for Windows 10/8/7/Vista/XP. The latest software prevents crashes and maximizes hardware and system performance. The PXIe 6361 has a recommended warm-up time of 15 minutes and should be externally calibrated at least once every 2 years.
The NI PXIe-6361 Multifunction I/O Module is well suited for many applications. These applications range from basic data logging to control and test automation. These modules have various industrial applications. The PXIe-6361 is used in laboratory research, design verification test, and manufacturing test.
The standard 3U PXI device weighs 7.2 oz. It has a recommended operating temperature range of 0 to 55 °C, a storage temperature range of -40 to 70 ºC, a random operating and non-operating vibration of 0.3 grms and 2.4 grms respectively (at a frequency of 5 to 500 Hz).
Associated Part Numbers: 193435B-03L, 193435C-03L, 781055-01
| Model | PXIe-6361 |
|---|---|
| Part Number | 781055-01 |
| Manufacturer | National Instruments |
| Type | PXI Multifunction I/O Module |
| Single-Ended Analog Input Channels | 16 |
| Differential Analog Input Channels | 8 |
| Maximum Sample Rate | 2 MS/s |
| Board Dimensions | Standard 3U PXI |
| Weight | 7.2 oz. |
| Warranty | Three Year Warranty |
| PXIe-6361 Manual | User Manual and Maintenance Manual Available for Download |
| Price | Contact a sales representative for a quote. |
National Instruments PXIe-6361 Frequently Asked Questions
Question: What is the slot compatibility of the PXIe-6361?
Answer: The slot compatibility for the PXIe-6361 is x1 and x4 PXI Express or PXI Express hybrid slots.
Question: How many I/O connectors does the NI PXIe-6361 have?
Answer: The NI PXIe-6361 has one 68-pin VHDCI I/O connectors.
Question: What is the analog input absolute accuracy for the PXIe-6361?
Answer: The analog input absolute accuracy for the PXIe-6361 is 1,660 uV.
Question: What is the ADC resolution of the NI PXIe-6361?
Answer: The ADC resolution of the NI PXIe-6361 is 16 bits.
PXIe-6361 PDF Manuals
DAQ GETTING STARTED GUIDE FOR PXI PXI EXPRESS.PDF
DAQ GETTING STARTED READ ME FIRST NI DAQMX AND DAQ DEVICE INSTALLATION GUIDE.PDF
NI 62XX 63XX PINOUT LABELS FOR THE SCB 68 NOTE TO USERS.PDF
NI 62XX 63XX PINOUT LABELS FOR THE SCB 68A NOTE TO USERS.PDF
NI 6361 DEVICE SPECIFICATIONS.PDF
NI PXIE 6361 63 LETTER OF VOLATILITY.PDF
