cDAQ-9136

4.5/5 | 16 ratings

Modular Systems > National Instruments > CompactDAQ

Part Number cDAQ-9136
Manufacturer/Brand National Instruments
Description: cDAQ-9136, 1.91 GHz Quad-Core, CompactDAQ Controller
Request for Availablility
Fast Quote
Quoted Price
Same Day Calibration Available
2-3 Year Warranty Included
Free Ground Shipping
  Get Pricing

Need an Official Quote?



Or speak to a sales representative for pricing & lead time:


National Instruments cDAQ-9136 CompactDAQ Controller

The cDAQ-9136 is a quad-core CompactDAQ Controller by National Instruments. The cDAQ-9136 is available in two versions with different OS. Part number 784238-01 has Windows Embedded Standard 7 installed and part number 784239-01 has Linux Real-Time installed. This model can control synchronization and timing functions and is also used to transfer data between C Series devices and a computer. The cDAQ-9136 is a 4-slot DAQ Controller, so four C Series I/O modules can be connected simultaneously. This feature enables the customization of digital and analog channels and timers/counters to design custom CAN measurement and logging systems.

The cDAQ-9136 CompactDAQ Controller features a 4-core Intel processor. The processor type is Intel Atom E3845. The CPU frequency is 1.91 GHz, and it has a hard drive memory space of 32 GB. The cache of the cDAQ 9136 processor has a memory of 2 MB. This model features an internal RT clock with 200 ppm accuracy. The cDAQ-9136 features analog inputs. The number of channels and maximum rate of sampling depends upon the C Series module(s). The NI cDAQ-9136 has a timing accuracy of 50 ppm for the analog inputs. The maximum update rate is 1.6 MS/sec. This model supports both periodic and non-periodic AO waveform modes.

The cDAQ-9136 CompactDAQ Controller incorporates many ports/terminals for different functions. This model has 2 Ethernet ports that support the network interface. These ports are IEEE 802.3 compatible, with communication rates of 10 Mbps, 100 Mbps, and 1000 Mbps auto-negotiated. The cDAQ-9136 also has an RS-232 port for serial communication. The serial port can sustain up to +24 V of overvoltage. Three USB ports are also available in the cDAQ-9136. These USB ports have a Hi-Speed 2.0 interface, with a maximum data rate of 480 Mb per second.

The NI device weighs 1.3 oz, and measures 8.54 x 3.47 x 4.67 in. in physical dimensions. It has a maximum power consumption value of 40 W, with a voltage input range of 9 to 30 V. Additionally, the controller has a recommended operating temperature range of -20 to 55 °C, and a storage temperature range of -40 to 85 °C.

ModelcDAQ-9136
ManufacturerNational Instruments
Part Numbers784238-01, 784239-01
TypeCompactDAQ Controller
Slots4
Hard Drive Memory Size32 GB
Processor Core1.91 GHz Quad-Core Intel Atom
Dimensions8.64 x 3.47 x 4.67 in.
Weight4 lb., 1.3 oz.
WarrantyThree Year Warranty
cDAQ-9136 ManualUser Manual and Maintenance Manual Available for Download
PriceContact a sales representative for a quote.

National Instruments cDAQ-9136 Frequently Asked Questions



Question: There are two part numbers listed for the cDAQ 9136 on the product page. Is there a difference between the part numbers?



Answer: Many NI products have several part numbers with slight differences. For example, part number 784238-01 for the cDAQ 9136 is compatible with Windows Embedded Standard 7 OS. However, part number 784239-01 is compatible with NI Linux Real-Time OS.



Question: What should I do if I have forgotten my password for the NI cDAQ-9136 and I need to format it?



Answer: The NI cDAQ-9136 has a RESET button which needs to be pressed and held for 10 seconds.


Question: Does LabVIEW 2014 support the cDAQ-9136?



Answer: The cDAQ-9136 can be used as a normal controller in any version of LabVIEW with DAQmx 15.1 or later installed (within reason.) However, real-time compatibility with the cDAQ-9136 was not introduced until LabVIEW Real-Time module 2015, which is only compatible with LabVIEW 2015. Thus, in order to use the cDAQ-9136 as a real-time controller, you'll need to have LabVIEW 2015 and LabVIEW real-time module 2015 or later. This note can be found in DAQmx 15.1 notes for supported devices.



Question: Can you use an HDMI cord with the NI cDAQ-9136?



Answer: HDMI cords are not compatible with the NI cDAQ-9136. It must be either active DVI or VGA.

  cDAQ-9136 PDF Manuals

Driver Downloads for cDAQ-9136






OS Compatibility:
Win XP 32-bit, Win 7 32-bit, Win 10 32-bit

 Download Version


Why Buy From Apex Waves:

Apex Waves Youtube Video


Delivery:
UPS, FedEX and DHL – Free FedEx Ground on all orders
Overnight, Next Day Air or Expedited shipping options available
International delivery available
Same day shipping for in-stock on location
Warranty: All of our products are covered by our Apex Waves Warranty.
3 Year Warranty - New Surplus Parts
2 Year Warranty - Refurbished Parts
Returns: No hassle return policy.
Dedicated customer service team.
Payment:
Quick Quotes: Receive Price & Availability Today!
Calibration: Ask About Our Tiered Calibration Levels
Option & Modules: Confirm Your Requirements or Versions
Repair: Cost & Lead Time Available Upon Request for Service
Repair Evaluation: $150
Share this page:
Associated Part Numbers:
Common Typos: VDAQ-9136, CEAQ-9136, CRAQ-9136, CDAQ-O136, CDAQ-91R6

cDAQ-9136


cDAQ-9136

cDAQ-9136, 1.91 GHz Quad-Core, CompactDAQ Controller

Request for Availablility
Same Day Calibration Available
2-3 Year Warranty Included
Free Ground Shipping
  Get Pricing

Call now for best pricing
1-800-915-6216

National Instruments cDAQ-9136 CompactDAQ Controller

The cDAQ-9136 is a quad-core CompactDAQ Controller by National Instruments. The cDAQ-9136 is available in two versions with different OS. Part number 784238-01 has Windows Embedded Standard 7 installed and part number 784239-01 has Linux Real-Time installed. This model can control synchronization and timing functions and is also used to transfer data between C Series devices and a computer. The cDAQ-9136 is a 4-slot DAQ Controller, so four C Series I/O modules can be connected simultaneously. This feature enables the customization of digital and analog channels and timers/counters to design custom CAN measurement and logging systems.

The cDAQ-9136 CompactDAQ Controller features a 4-core Intel processor. The processor type is Intel Atom E3845. The CPU frequency is 1.91 GHz, and it has a hard drive memory space of 32 GB. The cache of the cDAQ 9136 processor has a memory of 2 MB. This model features an internal RT clock with 200 ppm accuracy. The cDAQ-9136 features analog inputs. The number of channels and maximum rate of sampling depends upon the C Series module(s). The NI cDAQ-9136 has a timing accuracy of 50 ppm for the analog inputs. The maximum update rate is 1.6 MS/sec. This model supports both periodic and non-periodic AO waveform modes.

The cDAQ-9136 CompactDAQ Controller incorporates many ports/terminals for different functions. This model has 2 Ethernet ports that support the network interface. These ports are IEEE 802.3 compatible, with communication rates of 10 Mbps, 100 Mbps, and 1000 Mbps auto-negotiated. The cDAQ-9136 also has an RS-232 port for serial communication. The serial port can sustain up to +24 V of overvoltage. Three USB ports are also available in the cDAQ-9136. These USB ports have a Hi-Speed 2.0 interface, with a maximum data rate of 480 Mb per second.

The NI device weighs 1.3 oz, and measures 8.54 x 3.47 x 4.67 in. in physical dimensions. It has a maximum power consumption value of 40 W, with a voltage input range of 9 to 30 V. Additionally, the controller has a recommended operating temperature range of -20 to 55 °C, and a storage temperature range of -40 to 85 °C.

ModelcDAQ-9136
ManufacturerNational Instruments
Part Numbers784238-01, 784239-01
TypeCompactDAQ Controller
Slots4
Hard Drive Memory Size32 GB
Processor Core1.91 GHz Quad-Core Intel Atom
Dimensions8.64 x 3.47 x 4.67 in.
Weight4 lb., 1.3 oz.
WarrantyThree Year Warranty
cDAQ-9136 ManualUser Manual and Maintenance Manual Available for Download
PriceContact a sales representative for a quote.

National Instruments cDAQ-9136 Frequently Asked Questions



Question: There are two part numbers listed for the cDAQ 9136 on the product page. Is there a difference between the part numbers?



Answer: Many NI products have several part numbers with slight differences. For example, part number 784238-01 for the cDAQ 9136 is compatible with Windows Embedded Standard 7 OS. However, part number 784239-01 is compatible with NI Linux Real-Time OS.



Question: What should I do if I have forgotten my password for the NI cDAQ-9136 and I need to format it?



Answer: The NI cDAQ-9136 has a RESET button which needs to be pressed and held for 10 seconds.


Question: Does LabVIEW 2014 support the cDAQ-9136?



Answer: The cDAQ-9136 can be used as a normal controller in any version of LabVIEW with DAQmx 15.1 or later installed (within reason.) However, real-time compatibility with the cDAQ-9136 was not introduced until LabVIEW Real-Time module 2015, which is only compatible with LabVIEW 2015. Thus, in order to use the cDAQ-9136 as a real-time controller, you'll need to have LabVIEW 2015 and LabVIEW real-time module 2015 or later. This note can be found in DAQmx 15.1 notes for supported devices.



Question: Can you use an HDMI cord with the NI cDAQ-9136?



Answer: HDMI cords are not compatible with the NI cDAQ-9136. It must be either active DVI or VGA.

cDAQ-9136 PDF Manuals & Diagrams

  cDAQ-9136 PDF Manuals

NI CDAQ 9132 9134 9136 FOR LABVIEW REAL TIME QUICK START.PDF

NI CDAQ 9132 9134 9136 FOR WINDOWS QUICK START.PDF

NI CDAQ 9136 9137 LETTER OF VOLATILITY.PDF

NI CDAQ 9136 SAFETY ENVIRONMENTAL AND REGULATORY INFORMATION.PDF

NI CDAQ 9136 SPECIFICATIONS.PDF

CDAQ CHASSIS AND CONTROLLERS CALIBRATION PROCEDURE.PDF
