National Instruments NI-5752 Digitizer Adapter Module for FlexRIO

The NI-5752 is a Digitizer Adapter Module for FlexRIO from National Instruments. The NI 5752 is available under part number 781357-01. The NI-5752 can be used in conjunction with a PXI FPGA Module for FlexRIO. This module also supports interfacing with the PXI-795xR and PXIe-796xR modules. High-speed ADCs are used with it for data processing and streaming. This module features high-speed terminals for digitization. These terminals support a sampling rate to 50 MS/s maximum. The NI-5752 also features digital I/O links to interface with external hardware.

The NI-5752 Digitizer Adapter Module for FlexRIO has 32 analog inputs. The input terminals have a bandwidth of 14 MHz. The connector type for the input channels is dual stack 2-VHDCI. These input channels are AC-coupled. The input terminals of the NI 5752 are differential. However, the input channels are convertible into single-ended by setting the VGA gain to 6 dB. The module inputs have a maximum voltage swing of 2 Vpp (differential) and 1 Vpp (single-ended). This module has a sample Clock frequency range from 25 MHz to 50 MHz. The NI-5752 module also features two digital inputs and 16 digital outputs. The connector type for the digital I/O terminals is VHDCI. The maximum current of the digital outputs is 1 mA.

The NI 5752 module has one SMB connector and three VHDCI connectors. The NI-5752 supports Version 15.5 and above of the NI FlexRIO Driver. The module also supports an older NI FlexRIO Adapter Module Driver, which is versions 1.7 to 15.1 of this driver.

ModelNI-5752
ManufacturerNational Instruments
Part Number781357-01
TypeDigitizer Adapter Module for FlexRIO
Voltage Input Channels32
Maximum Sample Rate50 MS/s
Analog Input Resolution12 bits
Dimensions5.1 x 0.8 x 4.7 in.
Weight10 oz.
WarrantyOne Year Warranty
NI-5752 ManualUser Manual and Maintenance Manual Available for Download
PriceContact a sales representative for a quote.

National Instruments NI-5752 Frequently Asked Questions



Question: Which type of analog input coupling does the NI-5752 module have?



Answer: The NI-5752 has AC analog input coupling.



Question: What is the sample clock frequency range for the NI 5752?



Answer: The sample clock frequency range for the NI 5752 is 25 MHz to 50 MHz.



Question: What is the total power required for the NI-5752?



Answer: The total power required for the NI-5752 is 5.3 W.



Question: Which software is required for the NI 5752?



Answer: The following software is required for the NI 5752: LabVIEW, NI FlexRIO Adapter Module Support CD or the document Downloading the NI FlexRIO Adapter Module Software Note to Users, the LabVIEW FPGA Module, and NI-RIO device drivers.
