National Instruments PXI-6289 PXI Multifunction I/O Module
The National Instruments PXI-6289 is a PXI Multifunction I/O Module with 4 AO, 48 DIO, 32 AI, 18-Bit resolution, and 625 kS/s maximum sample rate. This model also offers two 32-bit counter/timers, analog triggering, as well as digital triggering. The NI PXI-6289 is known for its low cost, reliable DAQ capability and can be utilized in a broad range of applications in research, laboratory automation, design validation, etc. With this module, the user can add high-voltage measurement capability and sensors to a device by using SCXI or SCC signal conditioning modules. The PXI-6289 has two part numbers; the 779639-01 has a PXI hybrid bus connector and the 779123-01 has a PXI bus connector.
The NI PXI-6289 M Series DAQ is offered with a configuration utility and NI-DAQmx drivers. Thus, the user can easily configure this module. As far as its analog input characteristics are concerned, this module features 16 differential or 32 single-ended channels and 500 kS/s sample rate while operating in multichannel mode. In addition, it has 50 ns timing resolution, 50 ppm timing accuracy, and DC input coupling.
The NI PXI-6289 operates with >10 GΩ AI+ to AI GND and >10 GΩ AI- to AI GND input impedance in parallel with 100 pF. For data transfers, this model supports DMA (scatter-gather), programmed I/O and interrupts. The NI PXI-6289 M Series DAQ comes with integrated overvoltage protection for all sense and analog input channels, set at ±25 V for up to eight AI pins. This Multifunction I/O Module supports various triggering functions, including Pause Trigger, Sample Clock, start trigger, reference trigger, etc.
Model | PXI-6289 (779123-01, 779639-01) |
---|---|
Manufacturer | National Instruments |
Series | M Series |
Type | PXI Multifunction I/O Module |
Analog Input Channels | 32 |
Analog Input Resolution | 18 bits |
Dimensions | Standard 3U PXI |
Weight | 8.4 oz. |
Warranty | One Year Warranty |
PXI-6289 Manual | User Manual and Maintenance Manual Available for Download |
Price | Contact a sales representative for a quote. |
National Instruments PXI-6289 Frequently Asked Questions
Question: Where can I find the PXI-6289 specifications?
Answer: The PXI-6289 specifications are under the technical specifications tab on the product page.
Question: How many I/O connectors are on the NI PXI-6289 M Series DAQ?
Answer: There are two 68-pin VHDCI I/O connectors on the NI PXI-6289 M Series DAQ.
Question: What is the PXI 6289 maximum sample rate?
Answer: The PXI 6289 maximum sample rate is 625 kS/s.
Question: How many analog output channels does the NI PXI-6289 have?
Answer: The NI PXI-6289 has 4 analog output channels.
PXI-6289 PDF Manuals
DAQ GETTING STARTED GUIDE FOR PXI PXI EXPRESS.PDF
DAQ GETTING STARTED READ ME FIRST NI DAQMX AND DAQ DEVICE INSTALLATION GUIDE.PDF
NI 6289 DEVICE SPECIFICATIONS.PDF
NI 62XX 63XX PINOUT LABELS FOR THE SCB 68 NOTE TO USERS.PDF
NI 62XX 63XX PINOUT LABELS FOR THE SCB 68A NOTE TO USERS.PDF
PCI PXI 628X LETTER OF VOLATILITY.PDF
