National Instruments 778468-01 PXI Controller
The National Instruments 778468-01 PXI/CompactPCI embedded computer is a high-performance PXI/CompactPCI system controller- and it is the identifying number for the version of the PXI-8101 model made for Windows 2000. With cutting-edge packaging technology, the 778468-01, intended for industrial and laboratory applications, combines several common I/O functions into a single, small unit. It creates a small, durable, fully PC-compatible computer system when paired with a PXI-compatible chassis such as the NI PXI-1042.
With a 2.00 GHz Intel® Celeron 575 CPU, the 778468-01 provides strong performance for demanding workloads. Processing power is ensured by this single-core processor, which is paired with a 1 MB L2 cache and a 667 MHz front-side bus (FSB). With 1 GB of DDR2 RAM that can be expanded to 4 GB, the controller has more than enough capacity for a variety of activities. To ensure there is enough room for data and software, storage options include a minimum of 80 GB Serial ATA hard disk or a 4 GB flash drive.
The 778468-01's extensive range of I/O ports improves its adaptability and communication. It has two Hi-Speed USB 2.0 ports, an RS-232 serial connector, a parallel port, and a DVI-I port for digital and analog video output. It also has a PXI trigger bus input/output for synchronization with other PXI modules and Gigabit Ethernet for fast network connectivity. Interestingly, there is no PS/2 keyboard or mouse connector included with the controller.
There are several operating systems pre-installed on the 778468-01, including Windows 7 Professional, Windows Vista Business, and Windows Vista Business degraded to Windows XP Professional. Software tools such as LabVIEW, Measurement Studio, and LabWindows/CVI from National Instruments are compatible with this controller. PXI system customization and complete control are made possible by these ADE environments in conjunction with hardware drivers like as NI-DAQmx.
Because of its modular design, which follows the PXI 3U-size form factor, the 778468-01 is compatible with a large number of PXI chassis and modules. It is the perfect option for a range of industrial and laboratory applications, including data collecting and control, automated test systems, and integrated peripheral I/O, thanks to its sturdy construction.
Part Number | 778468-01 |
---|---|
Model Name | PXI-8101 |
Part Type | PXI Controller |
Processor | Intel® Celeron® Processor 575 (2.00 GHz single core) |
Memory | 1 GB DDR2 RAM, expandable to 4 GB |
Storage | 80 GB Serial ATA hard drive or 4 GB Flash drive |
Ethernet | 10/100/1000 BaseTX |
USB Ports | 2 Hi-Speed USB 2.0 ports |
Video Output | DVI-I (Analog/Digital) |
Serial Port | 1 RS-232 |
778468-01 PDF Manuals
NI PXI 8101 8102 INSTALLATION GUIDE.PDF
NI PXI 8101 8102 USER MANUAL AND SPECIFICATIONS.PDF
NI PXI 8101 8102 8108 8110 LETTER OF VOLATILITY.PDF
NI PXI PXIE 8101 LETTER OF VOLATILITY.PDF
PXI 8101 DIMENSIONAL DRAWING.PDF
