National Instruments PXI-7811R PXI Digital Reconfigurable I/O Module

The PXI-7811R (Part Number: 778800-01) PXI Digital Reconfigurable I/O Module has 160 DIO and a Virtex-II 1M FPGA. The client programmable FPGA can be used for internal preparing and adaptable E/O tasks. With LabVIEW FPGA, the user can separately design advanced lines, such as inputs, outputs, counters/timers, PWMs, encoder inputs, or specialized communication protocols. The user can also plan inward basic decisions that keep running with equipment-based speed and reliability. The PXI-7811R is perfect for a wide assortment of utilizations, which includes fast waveform generation, sensor reenactment, hardware-in-the-loop (HIL) testing, custom communication conventions, error rate testing in bits, and different applications that require exact timing and control.

The NI PXI-7811R PXI Digital Reconfigurable I/O Module requires the NI-RIO 1.3 or later driver software and the LabVIEW FPGA Module 7.1 or later. This module also requires one connector block and one cable. The cable recommended is a 1 m shielded SHC68-68-RDIO Cable and a recommended Connector Block is the SCB-68A Spring-Screw_Terminals Connector Block.

The National Instruments PXI-7811R comes with an instrumentation enhancer that applies common-mode voltage rejection and introduces high input impedance to the AI signals associated with the module. Information multiplexers on the gadget course signals to the positive and negative contributions of the instrumentation enhancer. The instrumentation intensifier changes over two input signals to a signal that is the distinction between the two input signals. The amplifier output voltage is referenced to the gadget ground. The NI PXI-7811R ADC measures this output voltage when it performs A/D conversions. In this model, a floating signal source is not associated with the building ground framework, but instead it has an isolated ground-reference point. A few cases of floating signal sources are outputs of transformers, thermocouples, battery-powered gadgets, optical isolator outputs, and isolation enhancers.

PXI-7811 Obsolete Status has been announced by National Instruments, but the module will still be available for purchase and repairs by Apex Waves.

ModelPXI-7811R
ManufacturerNational Instruments
Part Number778800-01
SeriesR Series
TypePXI Digital Reconfigurable I/O Module
FPGAVirtex-II 1M
Digital I/O160
Dimensions6.3 x 3.9 in.
Weight152 g.
WarrantyOne Year Warranty
ManualUser Manual and Maintenance Manual Available for Download
PriceContact a sales representative for a quote.

National Instruments PXI-7811R Frequently Asked Questions



Question: What type of I/O connectors are on the PXI-7811R?



Answer: There are four 68-pin female high-density VHDCI I/O connectors on the PXI-7811R.



Question: How long does the NI PXI-7811R take to warm up?



Answer: The NI PXI-7811R takes 15 minutes to warm up.



Question: What is the embedded block RAM size of the PXI-7811R?



Answer: The embedded block RAM size of the PXI-7811R is 720 kbits.



Question: Where can I find the PXI-7811R user manual?



Answer: The PXI-7811R user manual can be downloaded from the Apex Waves’ website.
