National Instruments PXI-7841 PXI Multifunction Reconfigurable I/O Module

The PXI-7841 (Part Number: 780337-01) Multifunction Reconfigurable I/O Module is made by National Instruments. The device is equipped with a built-in Virtex-5 LX30 FPGA module, which enhances the system’s performance and flexibility. This device has 8 analog input channels and 8 analog output channels. Each channel can perform at 200 kS/s maximum per channel. The device uses DIFF, RSE, and NRSE as input modes. Each mode is software-selectable and applicable to all channels. All input and output channels have 16-bit resolution. The device has the conversion time of about 4μs. The NI PXI-7841 has an input impedance around 10 GΩ. This rating is parallel with 100pF. This model performs DC coupling and has a maximum working voltage is within ±12 V. This is applicable for both single and common modes.

The National Instruments PXI-7841 Multifunction Reconfigurable I/O Module has a bandwidth of 1 MHz for small signals. The bandwidth increases up to 500 kHz for large signals. The device has 96 digital I/O Lines. The device has three 68-pin female I/O connectors. The connectors are VHDCI type with high density.

The NI PXI 7841 Multifunction Reconfigurable I/O Module has ±24 V maximum working voltage from channel to channel. The NI PXI-7841 fulfills the EMC standards. These standards are essential for lab use, control, and measurement. An important fact to note is that this module is easily cleanable with a non-metallic and soft brush. In addition, this module is recommended for indoor use only.

PXI-7841 Mature Status has been announced by National Instruments, but the module will still be available for purchase and repairs by Apex Waves.

ModelPXI-7841
ManufacturerNational Instruments
SeriesR Series
Part Number780337-01
TypePXI Multifunction Reconfigurable I/O Module
FPGA TypeVirtex-5 LX30
Analog Inputs8 (16 Bits, 200 kS/s)
Analog Outputs8 (16 Bits, 1 MS/s)
Number of Flip-flops19,200
Number of 25 × 18 Multipliers32
Embedded Block RAM1,152 kbits
Digital I/O96
Number of DMA Channels3
Timebase40, 80, 120, 160, or 200 MHz
I/O Connectors3 68-pin Female High-Density VHDCI
Power Requirements+3.3 VDC, +5 VDC, 12 VDC, –12 V - 525 mA, 125 mA, 0.5 A, 0.25 A
Dimensions6.3 in. by 3.9 in.
Weight0.34 lb.
Software DriverNI-RIO
Warranty2-3 Year Warranty
PXI-7841 ManualUser Manual and Maintenance Manual Available for Download
PriceContact a sales representative for a quote.

Associated part numbers for the PXI-7841:

198219A-04L, 198219B-04L, 198219C-04L, 198219D-04L, 198219E-04L, 780337-01

National Instruments PXI-7841 Frequently Asked Questions



Question: How can you customize the PXI-7841?



Answer: To customize the PXI-7841, you need the LabVIEW FPGA Module.



Question: Does the PXI 7841 have a dedicated A/D converter?



Answer: The PXI 7841 has one dedicated A/D converter per channel for independent timing.



Question: Is the NI PXI-7841 capable of multi-rate sampling?



Answer: The NI PXI-7841 offers multi-rate sampling and individual channel triggering.
