Anritsu S412E Land Mobile Radio Infrastructure Test Set
The Anritsu S412E is a multi-standard Land Mobile Radio (LMR) Test Set that is engineered for structured RF verification. This field instrument allows for comprehensive diagnostics that address complex requirements for LMR networks. The architecture implements advanced analysis blocks designed to evaluate diverse modulation formats. Each supported protocol is processed through dedicated demodulation stages that preserve signal integrity during decoding. The module has a daylight readable touchscreen that maintains operational clarity during outdoor measurements.
The broadband capabilities include analysis of LTE and WiMAX signals that assess wideband system behavior. These analyzers generate results that define performance boundaries across uplink and downlink conditions. The test unit includes a spectrum analyzer that operates from 9 kHz to 1.6 GHz with optional extension to 6 GHz. This range enables identification of spurious emissions that affect operational compliance across multi-service sites. The S412E LMR test set includes an internal power meter with support for an external sensor when extended ranges are required. Its hardware transitions efficiently between portable low power evaluations and high power transmitter testing. The handheld design supports battery operation for extended field assignments that require mobile capability. A built-in cable and antenna analyzer covers 500 kHz to 1.6 GHz with optional 6 GHz expansion. The S412E LMR unit measures return loss with VSWR insertion S11 and S21 along with precise DTF traces. The instrument further incorporates an interference analyzer that provides interference mapping with support for the MA2700A tool.
The S412E LMR test unit has small weight that remains under 3.4 kg which improves handling during long diagnostic sessions. Enhanced RF immunity within the unit reduces exposure to external interference that distorts measurements. Remote Ethernet control provides structured automation suited for coordinated test routines. It delivers sweep speeds of 850 microseconds per data point that support rapid scanning during dynamic assessments. Some of the accessories compatible with the test set include a carrying case, AC/DC power supplies, and a vehicle adapter. The unit also offers TIA-603-D compliant SINAD analysis and precise 20 dB quieting measurements capability.
| Model | Anritsu S412E |
|---|---|
| Manufacturer | Anritsu |
| Part Type | Land Mobile Radio Infrastructure Test Set |
| Supported Protocols | P25, P25 Phase 2, TETRA, DMR, dPMR, NXDN, NBFM, PTC |
| Broadband Analysis | LTE and WiMAX signal evaluation |
| Spectrum Analyzer Range | 9 kHz to 1.6 GHz, optional extension to 6 GHz |
| Cable and Antenna Analyzer | 500 kHz to 1.6 GHz, optional extension to 6 GHz |
| RF Measurements | Return Loss, VSWR, Insertion Loss, S11, S21, DTF |
| Interference Analysis | Interference mapping with MA2700A support |
| Weight | Less than 3.4 kg (7.6 lbs) including battery |
