Fluke 754 Documenting Process Calibrator
The Fluke 754 is recommended for the upkeep, calibration, and troubleshooting of HART and other instrumentation. This Documenting Process Calibrator can perform the following functions: source, simulate, and measure electrical signals, temperature, and pressure. The Fluke 754 has the communication capabilities of the 375 HART communicator, which includes: being simple to update, does not need an external box or more tools, provides quick HART communication, can read and write HART arrangement functions to perform field modifications, and various other valuable functions.
The Fluke 754 Documenting Process Calibrator can save a week of downloaded procedures and calibration outcomes, measure/source pressure utilizing a 29 Fluke 700Pxx Pressure Module, is compatible with numerous Asset management software packages, and comes with DPC/Track Sample software. This model is simple to operate with a multilingual user interface and a bright dual display screen. The battery life is normally around eight hours, enough to last a typical workday. As a bonus, replacing the batteries does not involve tools, which ensures that batteries can be easily replaced quickly.
The data log functions available on the Fluke 754 are: current, frequency, pressure, voltage, resistance, and temperature. The maximum input voltage is 50 V DC, while the maximum current is 25 mA, short circuit safeguarded. The autostep is additionally programmable for repeat, start delay, function, time, stepvalue, and time per step. The small size (5.4 x 9.6 x 2.5 inches) and minimal weight (2.7 pounds) make the Fluke 754 effortlessly transportable anywhere the user requires a Documenting Process Calibrator.
| Model | Fluke 754 |
|---|---|
| Manufacturer | Fluke |
| Type | Documenting Process Calibrator |
| Maximum Record Length | 8000 readings |
| Voltage | 26 V |
| Battery Life | 8 hours |
| Maximum Inpu Voltage | 30 V dc |
| Fluke 754 Manual | User Manual and Maintenance Manual Available for Download |
| Price | Contact a sales representative for a quote. |
