Keithley 2400-C SourceMeter
The Keithley 2400-C is a 1A, 20W, 200V SourceMeter SMU designed explicitly for test applications where tightly coupled sourcing and measurement is required. This instrument can also be used as a precise voltage and current source. The Keithley 2400-C offers around 0.012% basic accuracy with 6½-digit resolution. Since it is an SMU instrument, the 2400-C operates as a source in the first and third quadrant. However, it operates as a sink in the second and fourth quadrant. Thus, it delivers power to a load while working in the 1st and third quadrant and internally dissipates or sinks power while operating in the 2nd and 4rth quadrant.
The Keithley 2400-C comes with a robust sweep profile, since there are three primary sweep waveforms offered. These waveforms can be programmed for either single or continuous operation and the user will find them ideal for V/R, V/I, I/V, and I/R characterization. The Keithley 2400-C has a custom sweep function, which allows the construction of special sweeps. For more comfortable and faster testing, this model comes equipped with a built-in test sequencer (source memory list). This feature enables the creation and execution of a maximum of 100 different tests.
This SMU can make split Kelvin 6-wire guarded ohms measurements. The Keithley 2400-C features a digital I/O interface that can interconnect the instrument to various popular component handlers. This digital I/O interface offers signals to indicate the initiation and end of tests. Overall, the 2400-C is a powerful instrument for broad applications, such as testing passive devices, circuit protection devices, laser diodes, relays, switches, connectors, and more.
| Model | 2400-C |
|---|---|
| Manufacturer | Keithley |
| Series | 2400 Series |
| Type | SourceMeter (SMU) |
| Voltage Range | 200.00 V |
| Maximum Output Power | 22W, four quadrant source or sink operation |
| Source/Sink Limits | ±21V @ ±1.05A, ±210V @ ±105 mA |
| 2400-C Manual | User Manual and Maintenance Manual Available for Download |
| Price | Contact a sales representative for a quote. |
