Keithley DAQ6510 Data Acquisition and Logging Multi-Meter System
The Keithley DAQ6510 multimeter system is essential unit for measurements in industries. The unit delivers 6½ digit resolution that supports precise testing across different environments. It provides 15 integrated functions that support detailed characterization of diverse electrical parameters effectively. The unit measures voltage from 100 nV to 1000 V using 0.0025% accuracy consistently. The DAQ6510 multi-meter system supports current ranges starting at 10 pA and reaching a maximum of 3A. The instrument measures resistance values from 1 micro-Ohms to 120 mega-Ohms with stability. The capacitance function handles values between 0.1 pico-farad and 100 micro-farads accurately. The temperature capability supports thermocouples and RTDs and thermistors from -200 to 1820°C.
The built digitizer captures transient signals at 1 mega-sample per second with 16 resolution precision. The instrument stores 7 million readings that support extended logging across complex automation routines reliably. The system accepts 12 plug in switch modules that expand capacity to 8 independent channels. The front touchscreen uses a 5 inch display that enables graphical interaction during detailed evaluation. The multimeter unit DAQ6510 offers specified accuracy across 2 years ensuring traceable DC measurements under defined ranges. The standard communication interfaces include LAN LXI and USB TMC that support controlled integration tasks. The optional interfaces include GPIB and RS232 and TSP Link technology for advanced automation applications.
The switching architecture supports 10 distinct control modules that manage up to 80 DUT connections. The temperature scanning supports 82 pole channels that deliver consistent readings under varied conditions. The scanning system of DAQ6510 multimeter unit reaches 800 channels per second using the solid state module operation. The front panel jacks enable standalone DMM operation that supports direct measurements during maintenance activities. The Kick-Start software provides logging features that simplify control tasks during extended data acquisition procedures. The DAQ6510 maintains input bias current below 50 pico-amperes at 23 degrees Celsius operation. The common mode current stays under 600 nano-amperes peak-to-peak at industrial line frequencies. The Keithley DAQ6510 uses an internal design that reduces noise coupling to protect sensitive measurements from unwanted electromagnetic interference effects. The firmware architecture enables advanced sequencing that handles complex data workflows. The system supports modular expansion that protects investment through flexible configuration options for specialized testing.
| Model | DAQ6510 |
|---|---|
| Manufacturer | Keithley |
| Part Type | Data Acquisition and Logging Multi-Meter System |
| Resolution | 6½-digit measurement resolution |
| Voltage Measurement Range | 100 nV to 1000 V |
| Current Measurement Range | 10 pA to 3 A |
| Capacitance Range | 0.1 pF to 100 µF |
| Temperature Measurement Types | Thermocouple, RTD, Thermistor |
| Reading Memory Capacity | 7 million data readings |
| Switching / Channel Capacity | Up to 12 plug-in modules, 80 channels max |
