cRIO-9936, 10-Pin, Male COMBICON to 10-Pin, Female Screw Terminal, Terminal Block Plug
National Instruments cRIO-9936 Terminal Block Plug
The cRIO-9936 is a Terminal Block Plug. The NI cRIO-9936 is made with the part number 779105-01. The cRIO-9936 comes from the CompactRIO family. The cRIO-9936 Terminal Block Plug is also referred to as NI 9936 by the manufacturer. The NI cRIO-9936 Terminal Block Plug includes 10 screw terminal plugs. The National Instruments cRIO-9936 is designed to connect with any of the 10-position C Series screw terminal modules.
The NI cRIO-9936 Terminal Block Plug has a 10-Pin, Male COMBICON back end connection and a 10-Pin, Female Screw Terminal front end connection. The NI cRIO-9936 Terminal Block Plug provides direct connections to compatible C Series modules. The cRIO-9936 is useful for industrial, as well as academic experiments.
The National Instruments cRIO-9936 Terminal Block Plug helps decrease wiring on numerous devices and can be utilized for spare replacements. All the C Series modules can be acquired with the required connectors. If spare terminal block plugs are purchased, you can pre-wire them for fast connectivity between tests.
| Model | cRIO-9936 |
|---|---|
| Manufacturer | National Instruments |
| Part Number | 779105-01 |
| Type | Terminal Block Plug |
| Quantity | 10 |
| Back End Connection | 10-Pin, Male COMBICON |
| Front End Connection | 10-Pin, Female Screw Terminal |
| Compatible Devices | 10-position screw terminal C Series modules |
| Warranty | 2-3 Year Warranty |
| cRIO-9936 Manual | User Manual and Maintenance Manual Available for Download |
| Price | Contact a sales representative for a quote. |
