National Instruments cDAQ-9178 CompactDAQ Chassis

The National Instruments cDAQ-9178 is a CompactDAQ Chassis (Part Number: 781156-01) intended for little, versatile sensor estimation frameworks. The Chassis gives the plug and play simplicity of USB to sensor and electrical estimations. It also controls the timing, synchronization, and data transfer between C Series I/O modules and an external host. The user can utilize this frame with a mix of C Series I/O modules to make a blend of simple I/O, digital I/O, and counter/timer estimations. The device has an input FIFO size of 127 samples per slot, and has 8 slots. Also, the instrument’s maximum sample rate is determined by the C series module it is used with. The cDAQ-9178 additionally has four 32 bit universally useful counters/timers, which can be accessed by the user. The user can also share clocks and triggers through two implicit BNC connectors.

This model can be utilized to count edges, measure pulse widths, measure periods and frequencies, and perform position estimations (encoding). Also, the counter/timers can create pulses, pulse trains, and square waves with customizable frequencies. The user can access the counter sources of inputs and outputs by utilizing hardware-timed digital I/O modules installed in a maximum of two slots, or by utilizing the two frame PFI terminals.

For operation, the cDAQ-9178 may use the chassis trigger lines, a NI-9401 or a NI-9411 digital input module in any slot. The device operates using the NI-DAQmx software. The software supports a variety of Application Development Environments (ADEs) such as LabVIEW, LabWindows™ /CVI™, C/C++, C#, and Visual Basic .NET. On installing the software, the user only needs to install support for the ADE of their choice. Configuration of the software can be carried out using the Measurement & Automation Explorer (MAX) tool.

To perform analog input estimations, it is possible to insert a supported analog input C Series I/O module into any space on the CompactDAQ Chassis. The estimation specifications, such as number of channels, channel setup, test rate, and gain are determined by the type of C Series I/O module utilized. The NI cDAQ-9178 has three AI timing motors, which implies that three analog input tasks can be running at once on a chassis.

The cDAQ-9178 is available to be calibrated. While the recommended calibration period for individual parts varies, most parts should be calibrated either annually or every two years to ensure accuracy. If you need the cDAQ-9178 calibrated, Apex Waves provides options. We offer high-quality NIST accredited calibrations through a 3rd party, with an average turnaround time of 1 to 2 weeks. When you order the cDAQ-9178 with us, you can request basic (unaccredited) in-house calibration that will calibrate the part to the manufacturer specifications prior to being shipped. Call or email us today for more information about calibrating the cDAQ-9178!

ModelcDAQ-9178 (781156-01)
ManufacturerNational Instruments
SeriesCompactDAQ
TypeCompactDAQ Chassis
Slots8
Input FIFO Size127 samples per slot
Compatible ModelsC Series I/O Modules
Maximum Sample RateDetermined by C Series Module(s) it is used with
Dimensions10 x 3.47 x 1.21 in.
Weight31.0 oz.
WarrantyThree Year Warranty
cDAQ-9178 ManualUser Manual and Maintenance Manual Available for Download
PriceContact a sales representative for a quote.

National Instruments cDAQ-9178 Frequently Asked Questions



Question: What are the routing options for inputs on the cDAQ-9178?



Answer: The cDAQ-9178 has the following routing options for inputs: many internal signals, analog trigger, chassis PFI BNC, and any module PFI.



Question: How many general-purpose counters/timers does the cDAQ-9178 Chassis have?



Answer: There are 4 cDAQ-9178 counters.



Question: What are the dimensions of the NI cDAQ-9178?



Answer: The NI cDAQ-9178 dimensions are 10 x 3.47 x 1.31 in.



Question: What type of power connector does the NI cDAQ-9178 require?



Answer: The NI cDAQ-9178 power input mating connector s a Sauro CTF020V8, Phoenix Contact 1714977. The NI cDAQ-9178 power input connector is a 2 positions 3.5 mm pitch pluggable screw terminal with screw locks similar to Sauro CTMH020F8-0N001.



Question: What is the analog input timing resolution of the cDAQ-9178 Chassis?



Answer: The cDAQ-9178 Chassis has an analog timing resolution of 12.5 ns.
