National Instruments cDAQ-T1101 Temperature Measurement Bundle
The National Instruments cDAQ-T1101 Bundle (Part Number: 865682-01) is a compact, USB-based data acquisition system designed for precision temperature and low-voltage measurements in laboratory, industrial, and research environments. This integrated bundle consists of the NI-9213 C Series Temperature Input Module, the cDAQ-9171 CompactDAQ Chassis, and the cRIO-9940 Backshell; as a result, high-accuracy temperature measurements from thermocouples can now be made while providing excellent signal conditioning and mechanical protection.
The NI-9213 module features 16 differential analog input channels and has the ability to sample at 75 total samples per second. This module has an input voltage range of ±78 mV, with the ability for cold-junction compensation, open-thermocouple detection, and anti-aliasing filters and with its wide voltage range, this module provides precise temperature readings for various types of thermocouples. This module is NIST-traceable, offering good noise immunity and a good common-mode voltage range for applications that can introduce electrical interference or where the distance to the input sensor leads may be long.
The cDAQ-9171 chassis is a 1-slot USB data acquisition platform that also supports the C Series voltage measurement module. It has the ability to connect directly to the PC via USB, providing a “plug and play interface”, which can be configured and run by using NI's software tools such as LabVIEW and DAQExpress. The compact and light-weight construction of the chassis allows for differential measurements but still operates in a temperature range of -20 °C to 55 °C, allowing for good use in both bench testing and portable field measurement applications. Finally, the cRIO-9940 backshell provides good strain relief and electrical safety, preventing operators from high-voltage signals, while a secure connection is made to the thermocouple wiring.
The NI cDAQ-T1101 Bundle is typically applied to areas of industrial process monitoring, thermal validation experiments, energy efficiency studies and environmental test areas. The measurement accuracy of temperature acquisition, connection simplicity, and modular flexibility of the overall system provide a very reliable product for engineers requiring accurate multi-channel thermocouple readings from a compact, USB-powered data acquisition product.
| Model | cDAQ-T1101 Bundle |
|---|---|
| Part Number | 865682-01 |
| Part Type | Measurement Bundle |
| Components | NI-9213, cDAQ-9171, cRIO-9940 |
| Channels | 16 |
| Sample Rate | 75 S/s |
| Input Range | ±78 mV |
| Connectivity Interface | USB 2.0 |
| Operating Range | –20 °C to 55 °C |
| Measurement Features | CJC, Open-TC, Filter |
