Part Number NI-5752B
Manufacturer/Brand National Instruments
Description: NI-5752B, 32-Channel, Kintex-7 FPGA, Digitizer Adapter Module for FlexRIO
Lowest Price Guarantee
Fast Quote
Quoted Price
2-3 Year Warranty Included
Free Ground Shipping
  Get Pricing
2 year warrantyRefurbished
*What is Refurbished?
Quoted Price
Fully tested
2yr warranty
  Get Pricing

Need an Official Quote?


*Most customers receive their price in about 15 minutes.

Or speak to a sales representative for pricing & lead time:


National Instruments NI-5752B Digitizer Adapter Module for FlexRIO

The National Instruments NI-5752B (Part Number: 784062-01) is a 32-Channel, 12-Bit Digitizer Adapter Module for FlexRIO. This model is designed for FlexRIO systems, and it can acquire samples at 50 MS/s. The NI-5752B is usually used with a PXI FPGA Module - a combination that works as a high-speed digitizer and is capable of sampling up to 32 channels. With this module, users can also utilize high-performance A/D converters to achieve streaming of analog data and real-time processing. The NI-5752B comes with an integrated sample clock with 25 MHz to 50 MHz frequency range.

This Digitizer Adapter Module for FlexRIO is an ideal choice for applications where high data streaming rates and in-line data processing are required. The NI-5752B offers 32 differential, simultaneously sampled channels (AI 0 to AI 32), through 2 VHDCI (dual stack) connectors in AC-coupled mode. This module comes with a 12-bit A/D converter, with a variable gain amplifier. With this module, users can acquire Digital Inputs through 2 channels at 2.0 V Minimum high-level input voltage and 0.8 V Maximum low-level input voltage.

The NI 5752B module offers 16 DO channels through a VHDCI connector and can generate outputs at 1 mA maximum output current, 10 ns minimum pulse width, and 1 MHz maximum toggle frequency. The National Instruments NI-5752B requires 5.3 W of total power from the host FPGA device. In total, this module has one SMB connector and three 68-pin VHDCI connectors mounted on the front panel.

ModelNI-5752B
ManufacturerNational Instruments
Part Number784062-01
TypeDigitizer Adapter Module for FlexRIO
Voltage Input Channels32
Maximum Sample Rate50 MS/s
Analog Input Resolution12 bits
Dimensions5.1 x 0.8 x 4.7 in.
Weight10 oz.
WarrantyOne Year Warranty
NI-5752B ManualUser Manual and Maintenance Manual Available for Download
PriceContact a sales representative for a quote.

National Instruments NI-5752B Frequently Asked Questions



Question: What type of digital input and output connectors are on the NI-5752B?



Answer: There are VHDCI digital input and output connectors on the NI-5752B.



Question: What is the sample clock frequency range for the NI 5752B?



Answer: The NI 5752B has a sample clock frequency range of 25 MHz to 50 MHz.



Question: What type of FPGA is compatible with the NI-5752B?



Answer: The NI-5752B is compatible with Kintex-7 and Virtex-5 FPGAs.



Question: What is the total power requirement for the NI 5752B?



Answer: The total power requirement for the NI 5752B is 5.3 W.

  NI-5752B PDF Manuals


Why Buy From Apex Waves:

Apex Waves Youtube Video


Delivery:
UPS, FedEX and DHL – Free Fedex Ground on all orders
Overnight, Next Day Air or Expedited shipping options available
International delivery available
Same day shipping for in-stock on location
Warranty: All of our products are covered by our Apex Waves Warranty.
3 Year Warranty - New Surplus Parts
2 Year Warranty - Refurbished Parts
Returns: No hassle return policy.
Dedicated customer service team.
Payment:
Quick Quotes: Receive Price & Availability Today!
Calibration: Ask About Our Tiered Calibration Levels
Option & Modules: Confirm Your Requirements or Versions
Repair: Cost & Lead Time Available Upon Request for Service
Repair Evaluation: $150
