National Instruments PCMCIA-GPIB+ GPIB Interface and Analyzer
The National Instruments PCMCIA-GPIB+ is a GPIB Interface and Analyzer. The NI PCMCIA-GPIB+ is designed for PCMCIA slots found in laptop computers. You can use this GPIB Interface and Analyzer to integrate a GPIB compatible instrument into your system. The NI PCMCIA-GPIB+ is provided with a special cable that provides connectivity between the PCMCIA-GPIB+ and the GPIB port of the device to be connected. This GPIB Interface and Analyzer is fully compatible with IEEE 488.2 and HS488. The NI PCMCIA-GPIB+ is designed as a Type II card and fully adheres to the specifications determined by version 2.1 of the PCMCIA PC card standard. The inclusion of a National Instruments TNT family ASIC makes this device a robust GPIB interface.
This GPIB Interface and Analyzer is specially designed for low power consumption and portability. Thus, you can consider it for a variety of battery-powered applications. The NI PCMCIA-GPIB+ offers a wide range of analyzer capabilities as well. Thus, you can use your PCMCIA-GPIB+ to capture and monitor GPIB bus activity at high speeds. The 32-byte FIFO buffers data received or sent from the GPIB. This buffering of data brings a positive impact on the device’s data transfer rate.
The integrated analyzer in this device can sample at rates up to 20 MHz, while maintaining a timestamp resolution of 5 ns. This GPIB Interface and Analyzer is fully compatible with the Plug & Play standard. Thus, you can easily add or remove this device without restarting your system. The NI PCMCIA-GPIB+ comes with latching connectors to provide a powerful mechanical setup.
PCMCIA-GPIB+ Obsolete Status has been announced by National Instruments, but the GPIB Interface and Analyzer will still be available for purchase and repairs by Apex Waves.
| Model | PCMCIA-GPIB+ |
|---|---|
| Manufacturer | National Instruments |
| Part Numbers | 776945-02, 777157-02, and 778035-02 |
| Type | GPIB Interface and Analyzer |
| IEEE 488.1 Handshake Transfer Rate | 1.3 Mbytes/s |
| HS488 Transfer Rate | 2.2 Mbytes/s |
| OS | Win 3.1/DOS, Windows Me/9x, or Windows 2000/XP |
| Driver Software | NI-488.2 and Analyzer software |
| Size | Type II PC Card |
| PCMCIA-GPIB+ Manual | User Manual and Maintenance Manual Available for Download |
| Price | Contact a sales representative for a quote. |
