PXI-8422-4

Modular Systems > National Instruments > Serial Interface Devices

Part Number PXI-8422-4
Manufacturer/Brand National Instruments
Description PXI-8422/4 4-Port RS-232 Interface

Speak to a sales representative for pricing & lead time:


National Instruments PXI-8422/4 RS-232 Interface Module

The National Instruments PXI-8422/4 (Part number: 777736-04) is a 4-Port, Isolated, RS-232 Interface Module. This module incorporates a breakout box that associates with the SCSI 100-stick connector on the module and ends in four standard DB-9 male connectors.

 This model is an elite interface for rapid, port-to-port segregated communications with RS-232 gadgets. It includes superior DMA exchanges, multithreading, and a multiprocessor bolster. NI serial interfaces also show up as standard COM ports for similarity with programs that use serial communications.

The NI PXI-8422/4 RS-232 Interface Module comes with the TCP/IP communication convention, which handles all communications between the serial gadget server and the host PC that keeps running on inner firmware in the serial gadget server. A design utility arranges the IP address of the serial gadget server and uncovers all extra serial ports to the working framework for prompt use by any application programming bundle utilizing a standard Microsoft Windows Serial (COM) port interface.

This model has 2000 V with optical with port-to-port isolation, 64 B transmit and receive FIFOS (128 B with PXI-8422/4), DE9M (DB9) connectors without cables, and standard baud rates up to 115.2 kb/s.

The PXI-8422/4 RS-232 Interface Module common full-duplex multidrop bus architecture that includes a master-slave convention. Just a single gadget, the master, can control access to the bus. Every single other gadget is a slave. Slave gadgets must wait for the master to give them access to the bus. In a common system, one transmission line associates the bus master with all the slave receivers.

ModelPXI-8422/4
Part Number777736-04
ManufacturerNational Instruments
TypeRS-232 Serial Interface Module
Ports4
Maximum Transfer Rate115.2 kb/s
FIFO Size64 B
Dimensions3.94 x 6.37 in.
I/O Connector10-position modular jack (10P10C)
WarrantyOne Year Warranty
PXI-8422/4 ManualUser Manual and Maintenance Manual Available for Download
PriceContact a sales representative for a quote.

National Instruments PXI-8422/4 Frequently Asked Questions



Question: Which driver software should be used with the PXI-8422/4?



Answer: NI-Serial driver software is meant for the PXI-8422/4.



Question: Does the NI PXI-8422/4 have isolation?



Answer: Yes, the NI PXI-8422/4 has isolation.



Question: What is the data line ESD protection (HBM) for the PXI-8422/4?



Answer: The data line ESD protection (HBM) for the PXI-8422/4 is 15 kV.



Question: What signals are compatible with the NI PXI-8422/4?



Answer: The following signals are compatible with the NI PXI-8422/4: RXD, TXD, GND, RTS, and CTS signals.

PXI-8422-4 Technical Specifications:


Manufacturer:National Instruments
Model:PXI-8422/4 (777736-04)
Type:RS-232 Interface
Repair Evaluation:$150
