RADX Technologies PXIe-GPU-T400-2GB Catalyst PXIe-GPU Module
The PXIe-GPU-T400-2GB from RADX Technologies is a commercial off-the-shelf (COTS) PXIe-GPU module designed for even the most demanding systems. It is equipped with an integrated 2 GB Turing T400 PCIe professional GPU from NVIDIA, which has a 320 x CUDA core. By bringing the power of professional NVIDIA graphics into a standard PXIe chassis, this module eliminates the need for separate external GPU servers. It is especially well suited for challenging test and measurement applications including AI (artificial intelligence), video, signal, and images. The NVIDIA GPU includes a 1 x G6 NVENC for encoding video and a 1 × G4 NVDEC for decoding video.
Featuring robust software support, the PXIe-GPU-T400-2GB is compatible with both Windows 10 and 11, the 64-bit version of desktop Linux, and the RT Linux from NI. By providing full security compliance for Windows 11, this module helps solve a crucial operating system (OS) issue by replacing end-of-life integrated GPUs in legacy embedded controllers. It can be easily programmed in LabVIEW, Python, MATLAB, C, and C++.
This PXIe-GPU module is very power-efficient, requiring just one PXIe slot with 38 W of power per slot. Capable of safely operating in almost any recommended PXIe chassis, this module offers 3 x Mini DP 1.4a interfaces for the display. The PXIe-GPU-T400-2GB is equipped with a PXIe module thermal solution of a NVIDIA Fan Sink with an air flow of about 152 LFM.
This PXIe-GPU module should be operated in environments where the temperature ranges from 0 °C to 55 °C and the noncondensing humidity stays within the range of 10% to 90%. When not in use, it should be stored within a temperature range of -40 °C to 85 °C. The physical dimensions of the PXIe-GPU-T400-2GB measure 100 mm x 160 mm x 20.32 mm (3.94 in x 6.30 in x 0.80 in) and it has a light weight of only 0.4 kg (0.7 lbs).
Designed and assembled in the United States, this module is fully BAA/TAA compliant. It is available from authorized distributor Apex Waves!
| Model | PXIe-GPU-T400-2GB |
|---|---|
| Manufacturer | RADX |
| Part Type | RADX Catalyst & ORCA-C2X PXIeGPU |
| NVIDIA RTX GPU | Turing / Quadro T400 |
| GDDR6 / 7 | 2 GB, 80 GBPS |
| TFLOPS | 1.0 |
| CUDA RT-Tensor Cores | 384-0-0 |
| NVDEC | 1 x G4 |
| NVENC | 1 x G6 |
| Max W/Slot | 30 |
| Operating Temp Range | 0 °C to 55 °C |
| Storage Temp Range | -40 °C to 85 °C |
| Relative Humidity | 10% to 90%, noncondensing |
| Dimensions | 100 mm x 160 mm x 20.32 mm (3.94 in x 6.30 in x 0.80 in) |
| Weight | 0.4 kg (0.7 lbs) |
| Distributor | Apex Waves |
