LAN-3101B
Modular Systems > Spirent > SmartBits
| Description: | LAN-3101B, 6-Port, Ethernet SmartMetrics Module |
Need an Official Quote?
Or speak to a sales representative for additional information:
Phone:1-800-915-6216
Email:sales@apexwaves.com
Spirent SmartBits LAN-3101B Ethernet SmartMetrics Module
The SmartBits LAN-3101B is an Ethernet SmartMetrics Module. The manufacturer of the SmartBits LAN-3101B SmartMetrics Module is Spirent Communications. The LAN-3101B SmartMetrics Module is compatible with the Spirent SmartBits SMB-600x or SMB-6000x Chassis. The SMB-600x Chassis can accommodate two LAN-3101B SmartMetrics Modules, while the capacity of the SMB-6000x Chassis is up to twelve LAN-3101B modules. Equipped with internet protocol versions IPv4 and IPv6, high-density ports, and stream-based transmission and receiving modes, the LAN-3101B SmartMetrics Module is a fine choice among the family of Ethernet modules for its fast, efficient and dynamic operation.
The Spirent SmartBits LAN-3101B is a 6-port Ethernet SmartMetrics Module. The data transfer rate featured by the Spirent SmartBits LAN-3101B module is 10 Mbps or 100 Mbps. This transmission can either be manually fixed or auto negotiated. Each port of the SmartBits LAN-3101B Ethernet SmartMetrics Module can transmit up to 1,000 streams under IPv4 while up to 500 streams per port can be transmitted under IPv6. The SmartBits LAN-3101B module features half as well as full-duplex operation proving a dynamic and flexible device for the consumers. The frame length of the SmartBits LAN-3101B module is 24 – 16,000 bytes.
The Spirent SmartBits LAN-3101B Ethernet SmartMetrics Module features an RJ-45 connector. An interface SmartWindow GUI is provided with the SmartBits LAN-3101B module. This smart GUI eases the operation of the SmartBits LAN-3101B Ethernet SmartMetrics Module in a range of test systems including single as well as multiple devices. The compatibility of the SmartBits LAN-3101B module is with the 10Base-T and 100Base-TX systems that conform with the IEEE standards.
| Model | LAN-3101B |
|---|---|
| Manufacturer | Spirent Communications |
| Type | Ethernet SmartMetrics module |
| Number of Ports | 6 |
| Compatible Chassis | SMB-600x and SMB-6000x |
| Duplex Operation | Full/Half |
| Line Rate | 10/100 Mbps |
| Interface Type | IEEE 802.3 series 10Base-T, 100Base-TX |
| Connector Type | RJ-45 |
| Frame Length | 24 – 16000 bytes |
| Warranty | 2-3 Year Warranty |
| LAN-3101B User Manual | User Manual and Maintenance Manual Available for Download |
| Price | Contact a sales representative for a quote. |
