Tektronix TBS1032B Digital Storage Oscilloscope
The TBS1032B is a high-performance digital storage oscilloscope from Tektronix. The TBS1032B digital storage oscilloscope offers the frequency bandwidth up to 30 MHz and two channels at the output. The Tektronix TBS1032B digital storage oscilloscope comes with a 7-inch active TFT color display. This model supports advanced trigger capabilities, such as pulse triggers and line-selectable video triggers. These capabilities permit the user to complete various testing requirements more efficiently. The Tektronix TBS1032B also comes with the capability to automate measurements and can support up to 34 measurements simultaneously, which enhances the flexibility in terms of measurement capabilities for the users.
The Tektronix TBS1032B digital storage oscilloscope has an exceptional sample rate of 500 MS per second, which is supported across all channels. The instrument also offers a record length of 2.5 K points. This model has a vertical resolution of eight bits. The input sensitivity ranges from 2 mV to 5 volts per division and is integrated, along with the fine adjustment calibration capability. The horizontal system offers the time base range of 10 ns to 50 seconds per division. It offers the time base accuracy of 50 ppm.
The TBS1032B digital storage oscilloscope provides accurate measurements at a quick speed. This model has the physical dimensions of 158.0 H x 326.3 W x 124.2 D and weighs around two kilograms. It enables the user to roam it around for various field applications. The TBS1032B also complies to the various regulatory requirements. This model has electromagnetic compatibility and safety features.
| Model | TBS1032B |
|---|---|
| Manufacturer | Tektronix |
| Series | TBS1000B |
| Type | Digital Storage Oscilloscope |
| Channels | 2 |
| Bandwidth | 30 MHz |
| Sample Rate | 500 MS/s |
| TBS1032B Manual | User Manual and Maintenance Manual Available for Download |
| Price | Contact a sales representative for a quote. |
