VIAVI SmartOTDR Handheld Fiber Tester
The VIAVI SmartOTDR handheld fiber tester gives precise diagnostics. The unit performs single dual and tri wavelength testing using 1310, 1550 and 1625 nm. It supports service evaluation on active networks without interrupting operational traffic. The unit integrates a 5-inch high visibility outdoor touchscreen that enhances field usability. It offers a light and compact construction that permits effective hands free operation. The tester provides an integrated continuous wave light source that strengthens fiber characterization tasks. The SmartOTDR tester enables testing through a one by one 128 splitter for PON verification. The tester includes automated fiber inspection that identifies contamination and macro-bend conditions with pass fail indicators. The system processes objective results that streamline acceptance workflows for diverse deployment environments. The instrument integrates a visual fault locator that assists in pinpointing discontinuities along fibers. The device includes an optical power meter that measures precise signal levels across supported wavelengths. The tester supports optional P5000i microscope connectivity that advances end face assessment accuracy.
The SmartOTDR tester unit simplifies optical time domain reflectometry analysis with the Smart Link Mapper option. The system upgrades easily in field environments that demand adaptable performance across technical roles. The device generates consistent results that reduce subjectivity and improve operational repeatability across teams. The handheld fiber tester enhances productivity with integrated support for USB Bluetooth and WiFi connectivity. The tester supports 3 giga-bit and four gigabit network access that enables remote coordination. The device maintains effective performance in 90% humidity which strengthens field reliability. The device offers all day battery operation that sustains uninterrupted testing cycles through extended shifts. The system includes a 3-year warranty that assures long term operational continuity for users.
The tester supports Smart Access Anywhere technology that establishes secure cloud based remote sessions. The instrument opens an encrypted tunnel that enables authorized personnel to operate the device remotely. The system supports WebDAV cloud services that allow instant sharing of measurement reports among teams. The VIAVI SmartOTDR handheld fiber tester module integrates seamless upload workflows that accelerate documentation and reduce procedural overhead. The device ensures accurate evaluation of optical paths that support efficient maintenance planning across networks.
| Model | SmartOTDR |
|---|---|
| Manufacturer | VIAVI |
| Part Type | Handheld Fiber Tester (OTDR) |
| Supported Wavelengths | 1310 nm / 1550 nm / 1625 nm (In-Service) |
| Display | 5-inch high-visibility outdoor touchscreen |
| Design | Lightweight, compact, hands-free design |
| PON Testing Capability | Testing through up to 1×128 splitter |
| Mobile Network Support | 3G / 4G via USB or wireless |
| Software Features | Smart Link Mapper (SLM) for simplified OTDR analysis |
